D3-16NE3 | Automation Direct 16 Point, 2 Common DC Powered Input Module

The D3-16NE3 is a 16-point input module designed for integration into PLC-based control systems within industrial automation environments. Categorized under PLCs and Machine Control, this input module belongs to the VDC Logic I/O category, serving as a critical component for processing and managing input signals in various automation applications. It is engineered to support both sinking and sourcing inputs, providing flexibility for use in systems where different signal types need to be monitored and controlled.

One of the key features of the D3-16NE3 is its ability to handle input voltages of 24 VAC or 24 VDC, making it versatile for a range of industrial applications that require monitoring AC and DC signals. This dual compatibility allows the module to be used in a variety of control systems, ensuring that it can integrate seamlessly with other automation components operating on different power sources. The module’s design supports robust signal processing, ensuring that both AC and DC signals are accurately detected and processed in real-time.

The D3-16NE3 is equipped with 16 discrete input points, providing ample capacity for monitoring multiple signals within an automation system. These input points are divided across two isolated commons, with each common supporting eight points. The isolated commons help to prevent electrical interference between different groups of inputs, enhancing the reliability and integrity of the signal processing. By isolating the input channels, the D3-16NE3 reduces the risk of electrical noise, signal cross-talk, and potential damage to the module or connected devices, ensuring stable and consistent performance across all input points.

The module is designed to handle both sinking and sourcing inputs, which further increases its versatility. Sinking inputs refer to circuits where current flows from the load into the input device, while sourcing inputs describe circuits where current flows from the input device to the load. This dual capability enables the D3-16NE3 to be used in a variety of industrial control applications, where the input devices may vary in terms of the signal types they output. Whether the system requires sinking or sourcing signals, the D3-16NE3 is capable of adapting to different input configurations without the need for additional hardware modifications.

The D3-16NE3 also comes with a removable terminal block, which simplifies the installation process by allowing for easy wiring and connection of input devices. This removable block enables fast and convenient access to the input terminals, making it easier for engineers and technicians to set up the module, troubleshoot wiring issues, or replace components without significant downtime. The inclusion of a removable terminal block also improves the overall maintainability of the system, ensuring that changes or upgrades can be made efficiently and with minimal disruption to operations.

In addition to its flexibility and ease of installation, the D3-16NE3 is designed for use in industrial environments where reliability and durability are key considerations. The module’s rugged construction ensures that it can operate consistently in demanding conditions, such as in environments where temperature fluctuations, electrical noise, or mechanical vibrations are common. The module’s ability to maintain reliable input signal processing in these conditions makes it an ideal choice for industries such as manufacturing, material handling, process control, and automated assembly lines.

By offering isolated commons and support for both AC and DC inputs, the D3-16NE3 provides a comprehensive solution for managing input signals in a variety of automation systems. Its capacity to handle 16 discrete input points ensures that it can manage complex control systems where numerous signals must be monitored simultaneously. This makes the D3-16NE3 a versatile and high-performance option for expanding the input capabilities of a PLC system, whether in small-scale applications or more complex industrial operations.

Overall, the D3-16NE3 16-point input module delivers a reliable and adaptable solution for handling discrete input signals in industrial control systems. Its dual support for sinking and sourcing inputs, combined with the ability to monitor both AC and DC signals, makes it a valuable asset for systems that require precise and flexible signal processing. With its removable terminal block, isolated commons, and robust design, the D3-16NE3 provides engineers and technicians with a practical and efficient tool for expanding the input capacity of their PLC systems while ensuring the stability and accuracy of signal monitoring across diverse industrial applications.
