D4-32TD1 | Automation Direct Discrete Output Module
D4-32TD1 | Automation Direct Discrete Output Module

D4-32TD1 | Automation Direct Discrete Output Module

Part #: D4-32TD1 Manufactured by: Automation Direct
Regular price
$294.00
Sale price
$294.00
Regular price
1 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The D4-32TD1 is a discrete output module by Automation Direct, part of the DL405 series. It features 32 sinking output poi...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: D4-32TD1
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Automation Direct
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
D4-32TD1 | Automation Direct Discrete Output Module
    D4-32TD1 | Automation Direct Discrete Output Module
D4-32TD1 | Automation Direct Discrete Output Module

Product Description P/N: D4-32TD1

Description / Specifications

Description

The D4-32TD1 is a discrete output module manufactured by Automation Direct. It provides 32 points of DC outputs and is designed for use in industrial automation systems. The module is compatible with DirectLogic PLCs and operates with 12-24 VDC. It is intended for controlling external devices through discrete on/off signals and is suitable for use in a variety of control applications.



Technical Specifications

Part #

D4-32TD1

Category

PLCs/Machine Control

Subcategory

VDC Logic I/O Module

Item

Output Module

I/O Module Type

Discrete

Series

DL405

Number of Output Points

32

Nominal Output Voltage

6-24 VDC

Discrete Output Type

Sinking

Number of Isolated Output Commons

4

Number of Points per Common

8

Load Current

0.2A/point, 1.6A/common

Fuse Type

User-supplied external fuse

Requires

ZIPLink pre-wired cable





Information About D4-32TD1


The D4-32TD1 is a discrete output module designed for use within PLC systems, specifically under the DL405 series from Automation Direct. This module is part of the VDC Logic I/O category, providing reliable control for external devices in industrial automation environments. As a 32-point discrete output module, the D4-32TD1 is ideal for applications requiring multiple control points, offering precise and efficient management of on/off signals for various processes and machinery.

One of the key features of the D4-32TD1 is its 32 discrete output points, which allow it to control up to 32 devices or signals simultaneously. The module is designed for use with nominal output voltages ranging from 6 to 24 VDC, making it versatile for different types of DC-powered equipment commonly found in industrial applications. This range of output voltage ensures compatibility with a variety of external devices, enabling the module to be integrated into both new and existing control systems with ease.

The discrete output type for this module is sinking, which means the D4-32TD1 outputs are configured to pull current through the load when the output is activated. Sinking outputs are commonly used in industrial settings due to their reliability and robustness in handling higher current loads. This makes the D4-32TD1 a practical choice for environments where multiple devices need to be controlled through discrete on/off signals.

The D4-32TD1 is designed with four isolated output commons, which play a crucial role in ensuring signal integrity and reducing the risk of electrical interference. Each isolated common can handle up to eight output points, providing further flexibility in organizing and managing output signals. By isolating the commons, the module minimizes the risk of cross-talk or signal noise between different output points, ensuring that each device or process receives a clean and accurate control signal.

In terms of load handling, the D4-32TD1 is capable of managing a load current of 0.2A per point, with a maximum of 1.6A per common. This load capacity is suitable for controlling small to medium-sized devices such as relays, solenoids, and other DC-powered actuators. The module’s load current specifications ensure that it can effectively manage the power requirements of most industrial devices, providing stable and reliable performance across all output points.

The D4-32TD1 requires a user-supplied external fuse for circuit protection. This allows users to select the appropriate fuse based on the specific requirements of their application, ensuring that the module and connected devices are properly protected from overcurrent conditions. The flexibility in fuse selection enables users to tailor the protection level to their specific control environment, ensuring long-term reliability and safety.

For ease of installation, the D4-32TD1 requires the use of a ZIPLink pre-wired cable. This pre-wired solution significantly reduces the time and complexity involved in wiring the module to external devices, offering a clean and efficient setup process. The ZIPLink cable eliminates the need for tedious point-to-point wiring, which reduces potential wiring errors and ensures a more streamlined installation. This feature makes the D4-32TD1 an excellent choice for environments where minimizing downtime during installation or maintenance is critical.

The D4-32TD1 output module is part of the DL405 series, a well-known family of PLCs designed for industrial automation. The DL405 series is recognized for its reliability, expandability, and ease of use, making it a trusted choice for engineers and system integrators. The D4-32TD1 seamlessly integrates with other components in the DL405 series, providing a reliable solution for expanding output capacity in complex automation systems.

Overall, the D4-32TD1 discrete output module delivers a versatile and reliable solution for managing multiple discrete output signals in industrial automation systems. With its 32 output points, 6-24 VDC nominal voltage range, and sinking output type, it is designed to handle a wide range of control tasks. The isolated commons and flexible load current specifications ensure safe and efficient operation, while the user-supplied fuse and ZIPLink cable requirements make it customizable and easy to install. Designed to integrate with the DL405 series, the D4-32TD1 offers the performance and reliability needed to meet the demands of modern industrial automation.
