D4-EX | Automation Direct Local Base Expansion Unit

The D4-EX is a local expansion unit designed for use with PLC systems in industrial automation environments. As part of the PLCs/Machine Control category, the D4-EX functions specifically within the subcategory of VDC Logic I/O Brain/Interface, serving as a local expansion I/O interface for extending the input/output capacity of existing control systems. This unit is essential for applications that require additional I/O channels but wish to avoid the cost and complexity of upgrading to a larger primary CPU or PLC system.

The D4-EX operates on an external power supply, requiring a voltage input of 110-220 VAC to function. This broad input voltage range allows for flexible deployment in different industrial and geographical settings, where voltage standards may vary. This flexibility ensures that the D4-EX can be used in diverse operational environments without the need for specialized power conversion equipment.

A key feature of the D4-EX is the inclusion of a 24 VDC, 400mA auxiliary power supply. This auxiliary power supply is designed to provide additional power to connected devices or components, further enhancing the flexibility and utility of the expansion unit. The 24 VDC output is commonly used in industrial applications, making the D4-EX compatible with a wide range of peripheral devices, sensors, and control systems that operate on this standard. This auxiliary power supply ensures that connected devices can operate efficiently without requiring additional external power sources, streamlining the installation process and reducing the overall complexity of the system configuration.

For seamless integration into an existing control system, the D4-EX requires the use of either the D4-EXCBL-1 or D4-EXCBL-2 external I/O expansion cables. These cables are specifically designed to link the expansion unit to the main PLC system, allowing for the smooth transfer of data and signals between the expansion unit and the primary controller. The use of dedicated expansion cables ensures reliable communication between the components, preventing signal loss or communication errors that could compromise the system's overall performance. The choice of cable length allows for flexible installation in various configurations, depending on the physical layout of the control system and the location of the primary PLC.

The D4-EX is designed to enhance the I/O capacity of PLC systems without sacrificing performance or reliability. It enables users to extend the capabilities of their control systems by adding additional local I/O, which can be critical in expanding production lines, managing complex automation processes, or incorporating new sensors and devices into an existing framework. This local expansion solution is ideal for industrial environments where scalability is important, but where a complete system overhaul is not feasible or necessary.

The D4-EX’s role as an I/O interface ensures that it can handle a variety of input/output configurations, making it versatile for use in different industries, such as manufacturing, material handling, process control, and factory automation. By integrating seamlessly with existing PLC systems, the D4-EX provides an effective solution for expanding control capabilities without the need for significant infrastructure changes or costly equipment upgrades.

In summary, the D4-EX local expansion unit is a high-performance, reliable, and flexible solution for increasing the I/O capacity of industrial control systems. Operating on 110-220 VAC and including a 24 VDC, 400mA auxiliary power supply, the D4-EX provides necessary power for connected devices, simplifying installation and system management. When used with the D4-EXCBL-1 or D4-EXCBL-2 external I/O expansion cables, the D4-EX enables smooth, reliable communication with the primary PLC system, ensuring efficient data and signal transmission. This expansion unit is a practical choice for industrial applications that demand scalability, reliability, and ease of integration.
