DA-2500 | Lutron 1HE Power Amplifier
- Regular price
- $219.00
- Sale price
- $219.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: DA-2500
Description
The Lutron DA‑2500 is a two-channel Class‑D power amplifier offering up to 2 × 500 W output per channel, compatible with 70 V/100 V and 8 Ω speaker systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Lighting
|
| Part Number | DA-2500 |
| Subcategory | Lighting Controller |
| RMS Power | 2x 500 W |
| Speakers Output | 100 V / 8 Ω |
| Input | 775 mV / 0 dB 10 kΩ |
| Frequency Response | L/H Cut OFF: 20 Hz ~ 20 kHz (+1 / -2 dB) L/H Cut ON: 70 Hz ~ 10 kHz (+1 / -3 dB) |
| S/N Ratio | > 80 dB |
| THD | < 0.1 % (1 kHz /-3 dBv, 100 W) |
| Cooling | Two Internal Fans |
| Indicators | Power, protection, clip & signal |
| Protection | Peak, short-circuit, overload & high temperature |
| Power Supply | 110 ~ 230 V AC 50 ~ 60 Hz |
| Consumption | 1050 W |
| Dimensions (mm) | 482 x 420 x 44 (1h rack 19") |
| Weight | 8.2 kgs |
Information About DA-2500
The DA-2500 is a high-performance Class-D power amplifier designed for commercial and professional audio applications. Delivering up to 2×500 W per channel into 70 V, 100 V, or 8 Ω speaker systems, it combines compact 1U rack-mount design with high efficiency and flexible input/output options. Ideal for public address and background music systems, the DA-2500 offers reliable power delivery, intelligent protection features, and versatile connectivity for modern sound installations.
Key Features:
- Dual-Channel Output: Provides up to 500 W per channel into high- or low-impedance loads.
- Class-D Efficiency: High-efficiency switching amplifier with up to 85% energy conversion.
- Flexible Speaker Support: Compatible with 70 V, 100 V, and 8 Ω speaker systems.
- Balanced Inputs: Dual Phoenix-type balanced line inputs with individual gain control.
- Smart Power Options: Accepts both 115–230 VAC and 24 V DC for primary or backup power.
- Comprehensive Protection: Built-in protection from short circuits, overloads, DC faults, and overheating.
- Visual Indicators: Front-panel LEDs for input signal, clip, protect, and output activity status.
- Compact Form Factor: 1U rack-mountable chassis (482 × 420 × 44 mm) saves rack space.
- Environment-Ready: Designed for reliable operation in commercial environments with variable power and thermal conditions.
The DA-2500 delivers powerful, efficient, and safe amplification—making it an ideal choice for distributed audio systems in corporate, hospitality, and institutional settings.
