Danfoss 080G5036 EKF Dual-Channel Stepper Valve Driver
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 080G5036
Description
The Danfoss 080G5036 is an EKF 2A stepper valve driver for controlling compatible motor-operated valves in refrigeration, air-conditioning, and heat-pump systems. It operates on 24 VAC/DC and provides two valve-drive channels with separate analog control inputs.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Danfoss |
| Category | Refrigeration Controls |
| Part Number | 080G5036 |
| Subcategory | Stepper Valve Drivers |
| Product Type | EKF 2A |
| Supply Voltage | 24 VAC/DC |
| AC Supply Frequency | 50/60 Hz |
| Stepper Valve Outputs | 2 |
| Supported Motor Types | Compatible bipolar and unipolar stepper motors |
| Analog Inputs | 2 |
| Selectable Input Signals | 0–5 V; 0–10 V; 4–20 mA; 0–20 mA |
| Digital Output | 1 open-collector output; maximum sink current 10 mA |
| Idle Power Consumption | Less than 1 W, without connected valves |
| Loaded Power Requirement | Depends on valve type; add both valve loads when using two channels |
| Configuration Method | DIP switches; compatible KoolProg/Koolkey tools |
| Mounting Format | DIN rail, four-module width |
| Operating Temperature | −20°C to 60°C (−4°F to 140°F) |
| Operating Humidity | Below 90% RH, non-condensing |
| Weight | 0.68 kg |
Information About 080G5036
The 080G5036 is part of the Danfoss EKF electronic valve-driver range. It supports compatible bipolar and unipolar stepper motors. DIP switches select the valve configuration and input signal for each channel. Status LEDs indicate valve movement and operating conditions during commissioning and servicing.
Key Features:
- Dual Valve Outputs: Drives two compatible stepper motor valves from one module.
- Independent Analog Inputs: Provides separate AI1 and AI2 control connections.
- Selectable Signal Types: Accepts 0–5 V, 0–10 V, 4–20 mA, or 0–20 mA inputs.
- Motor Compatibility: Supports specified bipolar and unipolar valve configurations.
- DIP-Switch Setup: Allows selection of valve type and analog input format.
- Status Indication: Uses LEDs to display valve operation and alarm conditions.
- Backup Power Interface: Includes an input for a compatible external backup supply.
- DIN-Rail Mounting: Uses a four-module DIN installation format.
The 080G5036 delivers the reliability and precision required for electronic stepper-valve positioning in compatible HVAC and refrigeration systems.
