Danfoss 132F0005 VLT Micro Drive FC 51 1.5 kW AC Drive

Danfoss 132F0005 VLT Micro Drive FC 51 1.5 kW AC Drive

Part #: 132F0005 Manufactured by: Danfoss

Regular price: $379.00
Sale price: $379.00
Regular price

1 in Stock

Condition: New-Surplus Original Box

Shipping calculated at checkout.

Product variants:

Quantity:

Product Overview

The Danfoss 132F0005 VLT Micro Drive FC 51 is a compact frequency converter for controlling compatible AC motors in indust... Read more

We accept:

Talk to a real expert.

+1 (828) 222-3490

sales@iqelectro.com

Mon–Sat, 7:00 AM – 8:00 PM (EST)

IQElectro 2-Year Warranty

Warranty for Product #: 132F0005

IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms

2-3 Day Free Shipping

Packed Ready to Ship

24/7 Expert Support

Return within 30-Days

IQElectro is Not an authorized distributor for Danfoss

Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 132F0005

Description / Specifications

Description

The Danfoss 132F0005 is a VLT Micro Drive FC 51 variable frequency AC drive designed to control the speed of compatible AC motors. It provides 1.5 kW (2 HP) output power, operates from a single-phase 200–240 V AC supply, and includes an integrated brake chopper and coated printed circuit board.

Technical Specifications

Condition	New/Never Used Surplus
Brand	Danfoss
Category	Industrial Automation
Part Number	132F0005
Subcategory	Variable Frequency Drives
Product Type	AC Frequency Converter
Product Series	VLT Micro Drive FC 51
Rated Power	1.5 kW (2 HP)
Input Voltage	200–240 V AC
Input Phase	Single-phase
Supply Frequency	50/60 Hz
Rated Output Current	6.8 A
Output Frequency	0–200 Hz (VVC+); 0–400 Hz (U/f)
Enclosure Rating	IP20
Frame Size	M2
RFI Filter	Class A1/B (C1)
Brake Chopper	Integrated
PCB Coating	Coated
Dimensions (H × W × D)	176 × 75 × 168 mm
Weight	4.19 lb

Information About 132F0005

The 132F0005 is a Danfoss VLT Micro Drive FC 51 frequency converter for general-purpose motor control applications. It supports single-phase input power from 200–240 V AC and provides a nominal output current of 6.8 A. The drive features an IP20 chassis enclosure, an RFI filter classified for Class A1/B (C1) applications, and a built-in brake chopper. Its M2 frame size supports compact installation in compatible industrial control panels.

Key Features:

Motor Power Rating: Supports AC motor applications up to 1.5 kW (2 HP).
Input Supply: Designed for single-phase 200–240 V AC operation.
Rated Output Current: Provides a nominal output current of 6.8 A.
Frequency Control: Supports output frequencies up to 200 Hz in VVC+ mode and 400 Hz in U/f mode.
Integrated Brake Chopper: Supports compatible braking resistor configurations.
RFI Filtering: Includes an RFI filter classified as A1/B (C1).
PCB Protection: Features a coated printed circuit board.
Compact Construction: Uses an M2 frame with an IP20 chassis enclosure.

The 132F0005 delivers the reliability and precision required for variable-speed AC motor control in compatible industrial equipment.
