Danfoss MCD6-0108B-T5-S1X-20-CV2 Advanced VLT MCD 600 Soft Starter 108A 200-525 VAC Three-Phase
- Regular price
- $2,199.00
- Sale price
- $2,199.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: MCD6-0108B-T5-S1X-20-CV2
Description
The Danfoss MCD6-0108B-T5-S1X-20-CV2 is an advanced VLT® MCD 600 soft starter designed to provide controlled starting and stopping of three-phase induction motors. Featuring an integrated bypass contactor and comprehensive motor protection, the Danfoss MCD6-0108B-T5-S1X-20-CV2 minimizes mechanical stress, reduces electrical inrush current, and improves the operational reliability of industrial motor-driven equipment. It is suitable for pumps, conveyors, compressors, fans, crushers, mixers, and other fixed-speed applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Danfoss |
| Category | Drives |
| Part Number | MCD6-0108B-T5-S1X-20-CV2 |
| Subcategory | Soft Start |
| Product Type | Advanced Soft Starter |
| Series | VLT® MCD 600 |
| Input Phases | 3 |
| Supply Voltage | 200–525 VAC |
| Control Voltage | 110–120 VAC or 220–240 VAC (CV2) |
| Current Rating | 108 A |
| Enclosure Rating | IP20 |
| Frame Size | S1 |
| Integrated Bypass | Yes |
| Dimensions | 336 × 152 × 231 mm |
| ECCN | EAR99 |
| Weight | 14.00 lbs |
Information About MCD6-0108B-T5-S1X-20-CV2
The MCD6-0108B-T5-S1X-20-CV2 is a member of the Danfoss VLT® MCD 600 series of advanced digital soft starters engineered for demanding industrial motor control applications. This internally bypassed soft starter operates from a 200–525 VAC three-phase supply and is housed in an IP20 enclosure with an S1 frame, providing a compact solution for panel-mounted installations. It incorporates Adaptive Acceleration Control (AAC), advanced motor protection, DC injection braking, programmable start and stop profiles, and extensive communication options including EtherNet/IP, PROFINET, Modbus, PROFIBUS, and DeviceNet through optional modules. Designed for long-term reliability, it offers graphical programming, event logging, USB data transfer, and intelligent diagnostics that simplify commissioning and maintenance.
Key Features:
- Advanced Soft Starting: Reduces motor inrush current and mechanical stress during startup.
- Integrated Bypass Contactor: Improves operating efficiency while reducing heat generation during normal motor operation.
- Three-Phase Operation: Designed for 200–525 VAC three-phase industrial power systems.
- Adaptive Acceleration Control: Automatically optimizes starting and stopping profiles for various load conditions.
- Comprehensive Motor Protection: Includes overload, current imbalance, undercurrent, overcurrent, thermistor, and input fault protection.
- Industrial Communication Support: Compatible with EtherNet/IP, PROFINET, PROFIBUS, Modbus RTU, Modbus TCP, and DeviceNet using optional communication cards.
- Graphical User Interface: Four-line display and intuitive programming menus simplify configuration and diagnostics.
- Compact IP20 Design: S1 frame construction allows efficient installation in industrial control cabinets.
The MCD6-0108B-T5-S1X-20-CV2 delivers the reliability and precision required for advanced industrial soft starting and motor protection applications.
