Datalogic S80-MH-5-Y09-PPIZ 4 m Laser Distance Sensor
- Regular price
- $1,172.00
- Sale price
- $1,172.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: S80-MH-5-Y09-PPIZ
Description
The Datalogic S80-MH-5-Y09-PPIZ is a laser distance sensor designed for non-contact distance measurement and object-position monitoring in industrial automation systems. It measures distances from 0.3 to 4 meters and provides PNP switching outputs, a 4–20 mA analog output, and an RS485 serial interface. Its aluminum housing and IP67 protection rating support use in demanding industrial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Datalogic |
| Category | Sensors & Switches |
| Part Number | S80-MH-5-Y09-PPIZ |
| Subcategory | Laser Distance Sensors |
| Order Number | 951501080 |
| Measurement Range | 0.3–4 m |
| Sensing Technology | Laser time-of-flight |
| Laser Wavelength | 658 nm, red Class 2 |
| Output Type | 2 PNP normally open outputs |
| Analog Output | 4–20 mA |
| Communication Interface | RS485 |
| Supply Voltage | 15–30 V DC |
| Connection | M12, 8-pin connector |
| Protection Rating | IP67 |
| Housing Material | Aluminum |
| Response Time | 5 ms normal / 1 ms fast mode |
| Weight | 0.73 lb |
Information About S80-MH-5-Y09-PPIZ
The S80-MH-5-Y09-PPIZ belongs to Datalogic's S80 series of laser distance sensors, which use time-of-flight measurement technology. This model is designed for direct measurement without a reflector, with a specified range of up to 4 meters. It uses a red 658 nm Class 2 laser and provides distance data through analog, digital, and serial interfaces. Typical applications include pallet positioning, level monitoring, and measuring the position of moving materials on automated equipment.
Key Features:
-
4 m Measurement Range: Measures target distance from 0.3 to 4 meters.
-
Laser Time-of-Flight Technology: Supports non-contact distance measurement.
-
PNP Switching Outputs: Provides two PNP normally open outputs.
-
4–20 mA Analog Output: Sends distance measurements to compatible controllers.
-
RS485 Interface: Supports serial communication with compatible automation systems.
-
658 nm Red Laser: Uses a Class 2 visible red laser emitter.
-
IP67 Protection: Designed to resist dust ingress and temporary water immersion under specified conditions.
-
Aluminum Housing: Provides a robust enclosure for industrial installations.
The S80-MH-5-Y09-PPIZ delivers precise distance sensing and flexible signal integration for compatible industrial automation applications.
