DC2-56U | Reliance Electric Open Chassis Rockwell Flat Plate Motor Controller 56U

Description

The DC2-56U, also known as the Rockwell Flat Plate Motor Controller, is a component within Reliance Electric's System of parts. Housed in an open chassis enclosure, it is optimized for indoor usage in clean environments, with an ideal ambient temperature range of 0 to 55 degrees Celsius.

Equipped with a potentiometer for motor speed adjustment, the controller offers various customizable settings including current limits, minimum and maximum speeds. Additionally, it features a secondary IGBT and remote control capabilities, allowing users to interact with the device remotely. Integration into the system is facilitated through a product control interface.

The controller offers variable horsepower options of 1 or 2, with output current varying based on voltage settings. At 115V, it delivers an output current of 90KVA, while at 230V, it provides 180KVA. It boasts a 1-minute load capacity of 150% and an efficiency rating of 97%.

Operational on a single input phase, the system includes a 1.5KVA transformer and supports input voltages of 115V or 230V at 50/60Hz. Input ratings stand at 6.2A for 115V and 3.1A for 230V.

Technical Specifications

Information About DC2-56U

The Reliance Electric DC2-56U is a versatile and robust drive controller designed to meet the demands of various industrial applications. Part of the DC2 series, this drive controller offers reliable performance and is built to high standards by Reliance Electric, a trusted name in industrial automation.

The DC2-56U drive controller is engineered to handle motors with horsepower ratings of 1.0 and 2.0 HP, providing flexibility for different power requirements. This dual horsepower capability ensures that the controller can be utilized in a range of settings, from lower power applications to those requiring more substantial power output.

Operating with an input voltage of 115/230 VAC, the DC2-56U is designed to be compatible with standard industrial power supplies. This flexibility in input voltage allows for easy integration into existing electrical systems without the need for extensive modifications. Additionally, the drive controller operates on a single-phase power supply, making it suitable for a variety of industrial and commercial environments.

The DC2-56U is capable of functioning at both 50Hz and 60Hz, which enhances its adaptability to different regional power standards. This frequency versatility ensures that the drive controller can be used globally, providing consistent performance regardless of the local power grid specifications.

One of the key advantages of the DC2-56U is its robust design and reliable operation. Reliance Electric has incorporated advanced engineering principles to ensure that this drive controller can withstand the rigors of industrial use. Its construction is aimed at providing long-term reliability, reducing the need for frequent maintenance and ensuring continuous operation in demanding environments.

The drive controller's user-friendly design includes features that facilitate easy installation and operation. The interface is straightforward, allowing operators to quickly set up and adjust the controller to meet specific application requirements. This ease of use minimizes downtime and maximizes productivity, as operators can make necessary adjustments without extensive training or technical support.

In terms of physical specifications, the DC2-56U is designed with a compact footprint, allowing for efficient use of space within control cabinets or machinery housings. Despite its compact size, the controller does not compromise on performance, delivering reliable power control in a small form factor.

Reliance Electric's commitment to quality is evident in the DC2-56U, with each unit manufactured to rigorous standards to ensure optimal performance and durability. This drive controller is built to handle the challenges of industrial applications, providing a dependable solution for motor control and power management.

In summary, the Reliance Electric DC2-56U drive controller is a highly versatile and reliable component designed for industrial applications requiring 1.0/2.0 HP motor control. With its compatibility with 115/230 VAC input voltage, single-phase operation, and ability to function at both 50Hz and 60Hz, the DC2-56U offers flexibility and adaptability for a wide range of settings. Its robust construction, user-friendly design, and compact size make it an ideal choice for ensuring efficient and reliable motor control in various industrial environments.
