Product Description P/N: DC2500-CE-0A00-200-00000-00-0
Description
The Honeywell DC2500-CE-0A00-200-00000-00-0 is a compact, high-performance universal digital controller designed for monitoring and managing temperature and process variables. It offers flexible input/output options and a dual display interface, making it suitable for a wide range of industrial control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
Controls & Indicators
|
| Part Number | DC2500-CE-0A00-200-00000-00-0 |
| Subcategory | Temperature/Process Control |
| Series | UDC2500 |
| Type | Universal Digital Controller |
| Power Supply | 90–264 VAC |
| Input Types | TC, RTD, mV, 0–5 V, (0)4–20 mA |
| Output 1 | 4–20 mA analog |
| Output 2 | Relay (alarm or control) |
| Display | Dual 4-digit LED |
| Size | ¼ DIN (96 x 96 mm front panel) |
| Certifications | CE, UL, CSA |
| Manual Language | English |
| Mounting | Panel mount |
| Housing Material | Flame-retardant plastic |
| Environmental Protection | NEMA 1/IP20 (panel-mounted use) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 70°C |
| Weight | 1.00 lbs (approx. 0.45 kg) |
Information About DC2500-CE-0A00-200-00000-00-0
The DC2500-CE-0A00-200-00000-00-0 is a model from Honeywell’s UDC2500 series of ¼ DIN digital controllers. Designed for use with thermocouples, RTDs, millivolt, voltage, or (0)4–20 mA signals, it supports a wide range of sensor types and process inputs. Output 1 is configured for isolated 4–20 mA analog control, while Output 2 provides relay-based alarm or control signaling. It operates with universal AC power input (90–264 VAC) and meets international certification standards, including CE, UL, and CSA. The controller features a user-friendly dual LED display for real-time process and setpoint visibility.
Key Features:
- Universal Input Compatibility: Accepts TC, RTD, mV, 0–5 V, and (0)4–20 mA inputs for broad sensor support.
- Analog and Relay Outputs: Provides 4–20 mA control output and relay output for alarms or process actuation.
- Dual Display Interface: Bright dual LED display allows concurrent viewing of process value and setpoint.
- Compact ¼ DIN Size: Standardized form factor for easy panel installation and replacement.
- Flexible Power Supply: Operates on a wide AC input range from 90 to 264 VAC.
- High Accuracy: Delivers precise measurement and control, suitable for both temperature and process variables.
- Safety Certified: Complies with CE, UL, and CSA standards for international usage.
- English Language Configuration: Supplied with English user interface and documentation.
The DC2500-CE-0A00-200-00000-00-0 delivers the reliability and flexibility required for modern process and temperature control systems.
