DM474X | Cognex DataMan 470 Non-Polarized Red LED Scanner
- Regular price
- $3,244.00
- Sale price
- $3,244.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: DM474X
Description
The Cognex DM474X is a high-performance image-based barcode scanner equipped with a non-polarized red LED light and advanced liquid lens options. Designed for high-speed industrial applications, it delivers superior image clarity and flexible autofocus, supporting dynamic vision tasks with precision and speed.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cognex |
| Category |
Vision Systems
|
| Part Number | DM474X |
| Subcategory | Smart Image-Based Scanners |
| Light Type | Non-Polarized Red LED |
| Lens Options | 10.3 mm M12 with IR-blocking filter; 16 mm F8 Liquid Lens |
| Sensor Type | 1/1.8" CMOS |
| Sensor Size | 7.2 mm x 5.4 mm |
| Pixel Size | 3.45 μm (square) |
| Resolution | 2048 x 1536 pixels |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 80°C (-4°F to 176°F) |
| Humidity | < 95% non-condensing |
| Environmental Protection | IP67 (with cable and proper lens cover) |
| Power Supply | 24 VDC ±10% |
| Power Consumption | 1.5 A max (HPIL), 250 mA (non-HPIL), 1000 mA (HPIA) |
| Weight | 373 g |
Information About DM474X
The DM474X is built for demanding scanning environments where adaptability and durability are key. It features a 1/1.8" CMOS image sensor with a resolution of 2048 x 1536 pixels, and pixel size of 3.45 μm, allowing for high-detail imaging. With integrated support for both 10.3 mm and 16 mm high-speed liquid lenses, this scanner delivers fast, electronic autofocus, enhanced by an IR-blocking filter. The unit is IP67-rated when used with appropriate covers, enabling use in dusty or wet industrial settings. It operates reliably in a temperature range of 0°C to 40°C and can be stored safely down to -20°C. Ideal for applications needing high-resolution image capture and flexible optics, it offers versatile integration into automation systems.
Key Features:
- High-Resolution Sensor: 1/1.8" CMOS with 2048 x 1536 pixel resolution for detailed imaging.
- Dual Lens Support: Includes 10.3 mm M12 lens with IR filter and 16 mm F8 autofocus lens options.
- Liquid Lens Autofocus: Enables rapid, electronic adjustment without mechanical movement.
- Built-in Illumination: Non-polarized red LED light ensures consistent illumination.
- Compact & Durable Design: Weighs 373 g with S-mount adapter; IP67-rated with appropriate covers.
- Power Efficiency: Operates on 24 VDC, with varied current draw based on configuration.
- Environmental Protection: Withstands humidity up to 95% (non-condensing) and wide storage temps.
- Precision Imaging: 7.2 mm x 5.4 mm sensor area with square 3.45 μm pixels ensures uniform sensitivity.
The DM474X combines high-resolution imaging, advanced lens technology, and robust construction to meet the needs of fast, accurate barcode and image-based scanning applications.
