DS200CVMAG3A | General Electric Cap/Fuse Voltage Monitor
- Regular price
- $2,215.00
- Sale price
- $2,215.00
- Regular price
-
Do you need more quantity?
Product Description P/N: DS200CVMAG3A
Description
The GE Generator Control Turbine Board DS200CVMAG3A is equipped with two 16-pin connectors and one 2-pin connector, along with six test points. The 16-pin connectors facilitate connection to ribbon cables, which convey control signals to various components and boards within the drive system. Due to the delicate nature of the ribbon cables, caution must be exercised during handling to prevent damage. When removing a ribbon cable, it is advisable to grasp the plastic connector firmly while stabilizing the board to prevent displacement. Visual inspection of the ribbon cables is recommended if the board exhibits operational issues post-startup, with particular attention to the integrity of wire connections to the plastic connector. In cases of wire disconnection, replacement of the ribbon cable is warranted.
The presence of six test points serves as a diagnostic aid for the board, permitting isolation and assessment of individual circuits. However, testing should only be conducted by qualified personnel due to safety considerations regarding board current and surrounding components. Proper selection and calibration of a suitable tester are imperative for accurate testing procedures.
Technical Specifications
Manufacturer |
GE General Electric |
Category |
Drives |
Subcategory |
Drive Board |
Series |
Mark V |
Part Number |
DS200CVMAG3A |
Functional Description |
Cap/Fuse Voltage Monitor Assembly |
Functional Acronym |
CVMA |
PCB Coating |
Normal Coating |
Functional Revision 1 |
A |
Information About DS200CVMAG3A
The GE Generator Control Turbine Board DS200CVMAG3A is furnished with two 16-pin connectors and one 2-pin connector. These connectors serve as interfaces for ribbon cables, which convey control signals to multiple components and boards within the drive system. The employment of ribbon cables necessitates careful handling due to the susceptibility of the fine wires to damage. It is recommended to firmly grip the plastic connector when extracting the ribbon cable from the board to mitigate potential harm. To ensure secure connection, one should verify the complete seating of the ribbon cable in the connector.
In instances where the board exhibits malfunction subsequent to drive initiation, scrutiny of the ribbon cables is advised. Visual examination of the fine wires at the junction with the plastic connector can elucidate potential issues, such as wire disconnection. If such discrepancies are observed, replacement of the ribbon cable is warranted to rectify the fault.
Moreover, the board incorporates six test points, facilitating diagnostic procedures. These test points are engineered to facilitate the isolation and evaluation of specific circuits within the board. It is imperative to note that testing endeavors should be entrusted solely to qualified personnel, given the inherent risks associated with board current and surrounding components. Furthermore, the utilization of a suitable tester, calibrated for the task at hand, is indispensable to ensure accurate diagnostic outcomes.
