Product Description P/N: DS200RTBAG3AHC
Description
The DS200RTBAG3AHC by General Electric is an RTBA Relay Terminal Board used in the Mark V turbine control system. It provides essential relay connections and signal routing, supporting efficient control and monitoring. This board ensures reliable signal transmission, enhancing the overall stability and performance of turbine operations.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | General Electric |
| Series | Mark V |
| Part Number | DS200RTBAG3AHC |
| Functional Description | Relay Terminal Board |
| Functional Acronym | RTBA |
| PCB Coating | Normal Coating |
| Functional Revision 1 | A |
| Functional Revision 2 | H |
| Artwork Revision | C |
Information About DS200RTBAG3AHC
The General Electric DS200RTBAG3AHC is a Relay Terminal Board designed for integration within the Mark V series control systems. This component, identified by its part number, serves a critical role in managing relay-based operations and interfacing with various external devices in complex industrial applications. The DS200RTBAG3AHC is essential for establishing reliable connections between the control system and external relays, facilitating the switching and control of various process elements.
As a Relay Terminal Board, the DS200RTBAG3AHC features a functional acronym "RTBA," denoting its primary role in handling relay connections. This board is equipped with multiple terminals designed to accommodate relay inputs and outputs, providing a flexible and organized solution for routing signals to and from the control system. The board’s design ensures that it can effectively manage the high-current and high-voltage demands associated with relay operations, contributing to the overall reliability and efficiency of the control system.
The DS200RTBAG3AHC is coated with a normal coating, offering protection to its printed circuit board (PCB) from environmental factors such as dust, moisture, and minor chemical exposure. This coating helps to enhance the board’s durability and reliability in standard industrial conditions. For applications in more challenging environments, additional protective measures may be necessary to safeguard the board from more severe conditions.
The board is designed with multiple functional revisions, indicating that it has undergone significant updates to improve its performance and compatibility. The first functional revision is marked as "1A," which reflects initial improvements made to the board's design and functionality since its original release. The second functional revision, "2H," denotes further refinements that enhance the board's performance, address any identified issues, or incorporate new technological advancements. These revisions ensure that the DS200RTBAG3AHC meets the evolving needs of industrial control systems and maintains compatibility with other Mark V series components.
In addition to functional revisions, the board features an artwork revision labeled "C." This revision pertains to updates in the layout and design of the board's physical components and circuitry. The artwork revision is crucial for optimizing the board's performance by improving component placement, trace routing, and overall manufacturing efficiency. These updates contribute to enhanced signal integrity, reduced electromagnetic interference, and better thermal management.
The DS200RTBAG3AHC is specifically designed for use within the Mark V control system, known for its robust and versatile capabilities in managing complex industrial processes. The board's relay terminal functionality allows it to interface with a wide range of external devices, including alarms, actuators, and other relay-based control elements. By providing a reliable and organized connection point for these devices, the DS200RTBAG3AHC plays a vital role in maintaining the stability and efficiency of the control system.
The board's design facilitates easy installation and integration within the Mark V system, ensuring that it can be quickly incorporated into existing setups or used as a replacement for older components. Its terminal connections are designed for straightforward wiring, reducing installation time and minimizing the potential for errors.
In summary, the General Electric DS200RTBAG3AHC Relay Terminal Board is a critical component for the Mark V control system, offering reliable management of relay connections and external devices. With its normal coating, multiple functional revisions, and updated artwork, the board provides enhanced durability, performance, and compatibility. Its role in facilitating efficient relay-based operations ensures that the Mark V system can effectively manage complex industrial processes, making it an indispensable part of any Mark V-equipped control system.
