DS3800NFLA | General Electric GE Mark IV Board

Description

The DS3800NFLA is a circuit board manufactured by General Electric as part of the Speedtronic Mark IV series, designed for turbine control. Serving as a daughter board, it expands the functionality of other boards by adding components.

On the left half of the DS3800NFLA, four diodes (CR1 to CR8) are arranged in two parallel columns, along with a smaller diode labeled CR11. Two brown resistors (R2 and R6) with red, black, gold, and silver bands are located nearby. Three silver transistors (Q1 to Q3) are arranged horizontally. Additionally, a 12-volt orange capacitor, a silver rectangular relay, and a long clear fuse with silver enclosures are present.

Bordering both ends are jumper pins, which, when connected, can alter the functions of the circuit board.

Technical Specifications

Information About DS3800NFLA

The General Electric DS3800NFLA is a specialized Fan Loss Card designed for integration within PLCs and machine control systems. As a critical component in the realm of industrial automation, this PC board PLC add-on board ensures the reliable detection and management of fan operation status, enhancing the overall safety and efficiency of the system.

Categorized under PLCs and Machine Control and subcategorized as a PC Board PLC/Add-On Board, the DS3800NFLA serves a specific and vital function. Its primary role is to monitor the operational status of cooling fans within the control system. Effective cooling is essential to maintain optimal temperatures and prevent overheating of sensitive components, ensuring the longevity and reliable performance of the system.

The DS3800NFLA functions as a daughter board, meaning it is designed to be an auxiliary component that extends the functionality of the main control board. This modular design approach allows for easy integration and scalability, enabling users to enhance their control systems without extensive modifications. The daughter board configuration also facilitates straightforward installation and maintenance, reducing downtime and operational disruptions.

In terms of its function, the DS3800NFLA Fan Loss Card is equipped to detect the failure or loss of cooling fans. This detection capability is crucial for maintaining system integrity, as it allows for timely intervention to address cooling issues before they escalate into more significant problems. By monitoring fan operation, the DS3800NFLA helps prevent overheating, which can lead to component failure and costly downtime.

The DS3800NFLA's robust design ensures reliable performance in demanding industrial environments. Built to withstand the harsh conditions typically encountered in industrial settings, this fan loss card is constructed with high-quality materials and components. Its durability and resilience ensure that it can perform consistently over extended periods, even in environments with high temperatures and vibrations.

This fan loss card is designed for seamless integration with GE's range of PLCs and machine control systems. Its compatibility with these systems ensures that it can be easily incorporated into existing setups, providing an immediate enhancement to system monitoring and protection capabilities. The DS3800NFLA's design and functionality align with GE's commitment to delivering advanced and reliable industrial automation solutions.

In summary, the General Electric DS3800NFLA Fan Loss Card is an essential add-on for PLC and machine control systems, offering critical monitoring and protection capabilities. Its role as a daughter board allows for easy integration and scalability, while its robust construction ensures reliable performance in harsh industrial environments. By effectively detecting and managing fan operation status, the DS3800NFLA helps maintain system integrity and prevent overheating, ensuring the longevity and reliability of the control system. This specialized component exemplifies GE's dedication to providing high-quality, innovative solutions for industrial automation and control.
