E3MC-A41 | Omron Diffuse-Reflective Photoelectric Switch 12–240V AC/DC Relay Output
- Regular price
- $1,499.00
- Sale price
- $1,499.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: E3MC-A41
Description
The Omron E3MC-A41 Photoelectric Switch Sensor is a compact, high-performance diffuse-reflective photoelectric sensor designed for reliable object detection across a wide range of industrial automation applications. Operating on a universal 12–240 V AC/DC supply, it features a relay output, Light-ON/Dark-ON selectable modes, and a long sensing range with stable performance in varying light conditions. Built for durability and ease of installation, the E3MC-A41 provides dependable, non-contact detection for manufacturing and process environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Sensors |
| Part Number | E3MC-A41 |
| Subcategory | Photoelectric Sensors |
| Series | E3MC Series |
| Type | Diffuse-Reflective Photoelectric Switch |
| Sensing Method | Diffuse-Reflective |
| Sensing Distance | Typically up to 300 mm (depending on target color and material) |
| Supply Voltage | 12–240 V AC/DC |
| Output Type | Relay Output |
| Operation Mode | Light-ON / Dark-ON (Selectable) |
| Response Time | Approximately 20 ms |
| Adjustment Method | Manual Sensitivity Control |
| Housing Material | Metal (Die-Cast Zinc Alloy) |
| Enclosure Rating | IP66 (Dustproof and Water-Resistant) |
| Connection Type | Prewired Cable (2 m standard) |
| Mounting Type | Bracket or Screw Mount |
| Indicators | Power and Operation LEDs |
| Operating Temperature | -25°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Protection Features | Surge Suppression, Overcurrent Protection |
| Standards Compliance | CE, UL, cUL |
| Application | Position Sensing, Object Detection, Conveyor and Packaging Systems |
| Country of Origin | Japan |
| Weight | Approx. 0.4 lbs (180 g) |
Information About E3MC-A41
The E3MC-A41 is part of the Omron E3MC Series, a proven line of photoelectric switches designed for precision detection and stable operation in both AC and DC control systems. Utilizing a diffuse-reflective sensing method, the sensor detects targets directly by receiving reflected light from their surface without requiring a reflector. This model is equipped with a relay output, making it ideal for driving contactors or interfacing with PLC input modules. With Light-ON/Dark-ON operation selection and manual sensitivity adjustment, it offers flexibility for various detection tasks. The E3MC-A41’s rugged metal housing and IP66-rated enclosure make it suitable for industrial use where vibration, dust, or moisture may be present.
Key Features:
- Diffuse-Reflective Detection: Detects objects based on reflected light without needing a reflector.
- Wide Voltage Range: Operates on 12–240 V AC/DC for flexible system compatibility.
- Relay Output Type: Provides direct switching for relays, PLCs, or contactors.
- Selectable Light/Dark Operation: Adaptable for different detection and output control needs.
- Manual Sensitivity Adjustment: Allows fine-tuning for consistent detection in variable conditions.
- Rugged Industrial Design: Metal housing ensures long-term durability and vibration resistance.
- Fast Response Time: Enables accurate detection for moving objects in automation lines.
- Sealed for Reliability: IP66-rated enclosure offers protection against dust and water ingress.
The E3MC-A41 delivers the reliability and precision required for industrial automation, object detection, and positioning applications.
Description
The Omron E3MC-A41 Photoelectric Switch Sensor is a compact, high-performance diffuse-reflective photoelectric sensor designed for reliable object detection across a wide range of industrial automation applications. Operating on a universal 12–240 V AC/DC supply, it features a relay output, Light-ON/Dark-ON selectable modes, and a long sensing range with stable performance in varying light conditions. Built for durability and ease of installation, the E3MC-A41 provides dependable, non-contact detection for manufacturing and process environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Sensors |
| Part Number | E3MC-A41 |
| Subcategory | Photoelectric Sensors |
| Series | E3MC Series |
| Type | Diffuse-Reflective Photoelectric Switch |
| Sensing Method | Diffuse-Reflective |
| Sensing Distance | Typically up to 300 mm (depending on target color and material) |
| Supply Voltage | 12–240 V AC/DC |
| Output Type | Relay Output |
| Operation Mode | Light-ON / Dark-ON (Selectable) |
| Response Time | Approximately 20 ms |
| Adjustment Method | Manual Sensitivity Control |
| Housing Material | Metal (Die-Cast Zinc Alloy) |
| Enclosure Rating | IP66 (Dustproof and Water-Resistant) |
| Connection Type | Prewired Cable (2 m standard) |
| Mounting Type | Bracket or Screw Mount |
| Indicators | Power and Operation LEDs |
| Operating Temperature | -25°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Protection Features | Surge Suppression, Overcurrent Protection |
| Standards Compliance | CE, UL, cUL |
| Application | Position Sensing, Object Detection, Conveyor and Packaging Systems |
| Country of Origin | Japan |
| Weight | Approx. 0.4 lbs (180 g) |
Information About E3MC-A41
The E3MC-A41 is part of the Omron E3MC Series, a proven line of photoelectric switches designed for precision detection and stable operation in both AC and DC control systems. Utilizing a diffuse-reflective sensing method, the sensor detects targets directly by receiving reflected light from their surface without requiring a reflector. This model is equipped with a relay output, making it ideal for driving contactors or interfacing with PLC input modules. With Light-ON/Dark-ON operation selection and manual sensitivity adjustment, it offers flexibility for various detection tasks. The E3MC-A41’s rugged metal housing and IP66-rated enclosure make it suitable for industrial use where vibration, dust, or moisture may be present.
Key Features:
- Diffuse-Reflective Detection: Detects objects based on reflected light without needing a reflector.
- Wide Voltage Range: Operates on 12–240 V AC/DC for flexible system compatibility.
- Relay Output Type: Provides direct switching for relays, PLCs, or contactors.
- Selectable Light/Dark Operation: Adaptable for different detection and output control needs.
- Manual Sensitivity Adjustment: Allows fine-tuning for consistent detection in variable conditions.
- Rugged Industrial Design: Metal housing ensures long-term durability and vibration resistance.
- Fast Response Time: Enables accurate detection for moving objects in automation lines.
- Sealed for Reliability: IP66-rated enclosure offers protection against dust and water ingress.
The E3MC-A41 delivers the reliability and precision required for industrial automation, object detection, and positioning applications.
