E3S-AT16 | Omron 7m Through-Beam Photoelectric Sensor NPN 10–30VDC
- Regular price
- $274.00
- Sale price
- $274.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: E3S-AT16
Description
The Omron E3S-AT16 is a through-beam photoelectric sensor set consisting of an emitter and receiver with a 7 meter sensing range. Operating on 10–30 VDC, it features an NPN digital output and selectable DARK-ON/LIGHT-ON modes for flexible control integration. Designed in a rectangular block style housing, it provides stable long-distance detection for industrial automation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Sensors |
| Part Number | E3S-AT16 |
| Subcategory | Through-Beam Photoelectric Sensors |
| Series | E3S-A Series |
| Sensor Type | Through-Beam (Emitter & Receiver Pair) |
| Sensing Distance | 7 m |
| Light Source | Red LED |
| Wavelength | 700 nm |
| Output Type | 1 × NPN Digital Output (30 VDC) |
| Operating Modes | DARK-ON / LIGHT-ON Selectable |
| Supply Voltage | 10–30 VDC (12–24 VDC Nominal) |
| Current Consumption | 20 mA Max |
| Connection Type | 2 m Pre-Wired Pigtail with 4-Pin M8 Connector |
| Mounting Method | Surface Mount with Through-Holes |
| Housing Material | Thermoplastic P.B.T. Polymer |
| Lens Material | Denatured Polyarylate |
| Protection Rating | IP67 |
| Operating Temperature | -25 °C to +55 °C |
| Weight | Approx. 0.25 kg |
Information About E3S-AT16
The E3S-AT16 is part of the Omron E3S-A series of built-in amplifier photoelectric sensors engineered for reliable industrial sensing. Configured as a through-beam emitter and receiver pair, it delivers extended detection capability with high resistance to background interference. The sensor utilizes a red LED light source at 700 nm and supports top-view, in-line horizontal sensing installations. With IP67 protection, thermoplastic P.B.T. housing, and pre-wired 2 m pigtail connections terminated with 4-pin M8 connectors, it is suitable for factory automation and material handling environments.
Key Features:
- 7 Meter Through-Beam Detection: Provides long-range and high-accuracy object sensing.
- Emitter and Receiver Pair: Ensures stable operation with minimal susceptibility to ambient light interference.
- NPN Digital Output (30 VDC): Compatible with standard PLC sinking input configurations.
- Selectable DARK-ON / LIGHT-ON Modes: Allows adaptation to application-specific control logic.
- 10–30 VDC Supply Voltage: Supports common industrial DC power systems.
- Red LED Light Source (700 nm): Delivers visible alignment assistance and stable beam performance.
- IP67 Protection Rating: Resistant to dust and water for harsh environments.
- Pre-Wired 2 m Cable with M8 Connector: Simplifies installation and maintenance.
The E3S-AT16 delivers the reliability and precision required for long-range industrial through-beam photoelectric detection applications.
Description
The Omron E3S-AT16 is a through-beam photoelectric sensor set consisting of an emitter and receiver with a 7 meter sensing range. Operating on 10–30 VDC, it features an NPN digital output and selectable DARK-ON/LIGHT-ON modes for flexible control integration. Designed in a rectangular block style housing, it provides stable long-distance detection for industrial automation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Sensors |
| Part Number | E3S-AT16 |
| Subcategory | Through-Beam Photoelectric Sensors |
| Series | E3S-A Series |
| Sensor Type | Through-Beam (Emitter & Receiver Pair) |
| Sensing Distance | 7 m |
| Light Source | Red LED |
| Wavelength | 700 nm |
| Output Type | 1 × NPN Digital Output (30 VDC) |
| Operating Modes | DARK-ON / LIGHT-ON Selectable |
| Supply Voltage | 10–30 VDC (12–24 VDC Nominal) |
| Current Consumption | 20 mA Max |
| Connection Type | 2 m Pre-Wired Pigtail with 4-Pin M8 Connector |
| Mounting Method | Surface Mount with Through-Holes |
| Housing Material | Thermoplastic P.B.T. Polymer |
| Lens Material | Denatured Polyarylate |
| Protection Rating | IP67 |
| Operating Temperature | -25 °C to +55 °C |
| Weight | Approx. 0.25 kg |
Information About E3S-AT16
The E3S-AT16 is part of the Omron E3S-A series of built-in amplifier photoelectric sensors engineered for reliable industrial sensing. Configured as a through-beam emitter and receiver pair, it delivers extended detection capability with high resistance to background interference. The sensor utilizes a red LED light source at 700 nm and supports top-view, in-line horizontal sensing installations. With IP67 protection, thermoplastic P.B.T. housing, and pre-wired 2 m pigtail connections terminated with 4-pin M8 connectors, it is suitable for factory automation and material handling environments.
Key Features:
- 7 Meter Through-Beam Detection: Provides long-range and high-accuracy object sensing.
- Emitter and Receiver Pair: Ensures stable operation with minimal susceptibility to ambient light interference.
- NPN Digital Output (30 VDC): Compatible with standard PLC sinking input configurations.
- Selectable DARK-ON / LIGHT-ON Modes: Allows adaptation to application-specific control logic.
- 10–30 VDC Supply Voltage: Supports common industrial DC power systems.
- Red LED Light Source (700 nm): Delivers visible alignment assistance and stable beam performance.
- IP67 Protection Rating: Resistant to dust and water for harsh environments.
- Pre-Wired 2 m Cable with M8 Connector: Simplifies installation and maintenance.
The E3S-AT16 delivers the reliability and precision required for long-range industrial through-beam photoelectric detection applications.
