E3ZM-CT61 | Omron Through-Beam Photoelectric Sensor 15m Range NPN Output Infrared LED IP67/IP69K Stainless Steel
- Regular price
- $409.00
- Sale price
- $409.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: E3ZM-CT61
Description
The Omron E3ZM-CT61 is a through-beam photoelectric sensor designed for long-distance object detection in industrial automation environments. The E3ZM-CT61 provides a sensing range of up to 15 meters using an infrared LED light source and features an NPN open-collector output for reliable control integration. It is built with a stainless steel housing and IP67/IP69K protection for use in harsh and oil-exposed applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Automation Control Modules |
| Part Number | E3ZM-CT61 |
| Subcategory | Photoelectric Sensors |
| Sensor Type | Through-Beam Photoelectric Sensor |
| Sensing Distance | 15 m (15000 mm) |
| Light Source | Infrared LED (870 nm) |
| Output Type | NPN Open Collector |
| Output Rating | 30 VDC Max, 100 mA Max |
| Operation Mode | Light-ON / Dark-ON Selectable |
| Response Time | 1 ms Max |
| Sensitivity Adjustment | Manual Single-Turn Adjustment |
| Power Supply Voltage | 10–30 VDC |
| Current Consumption | 20 mA Max (Emitter/Receiver) |
| Housing Material | SUS316L Stainless Steel |
| Connection Method | Prewired Cable |
| Cable Length | 2 m |
| Degree of Protection | IP67 / IP69K |
| Operating Temperature Range | -25°C to 55°C |
| Oil Resistance | Oil-Proof Design |
| Product Dimensions (H × W × D) | 32 mm × 10.8 mm × 21 mm |
| Weight | Approx. 150 g |
Information About E3ZM-CT61
The E3ZM-CT61 is part of Omron’s E3ZM series of durable photoelectric sensors engineered for industrial detection tasks requiring stable long-range sensing. It operates as a through-beam emitter/receiver system with selectable Light-ON and Dark-ON modes for flexible installation. The sensor includes manual sensitivity adjustment and fast 1 ms response time for accurate detection of opaque objects in high-speed automation processes. With SUS316L stainless steel construction, oil-resistant cabling, and high ingress protection ratings, it is designed for demanding machine environments such as packaging lines, food processing, and metalworking systems.
Key Features:
-
Through-Beam Photoelectric Sensing: Provides reliable object detection using separated emitter and receiver units.
-
15 m Long Sensing Distance: Supports extended-range detection for industrial conveyor and machine applications.
-
Infrared LED Light Source: Uses 870 nm infrared emission for stable sensing performance.
-
NPN Open-Collector Output: Compatible with industrial PLC input circuits up to 100 mA load.
-
Light-ON/Dark-ON Selectable Mode: Allows flexible output configuration based on application needs.
-
Fast 1 ms Response Time: Suitable for high-speed automation detection and control tasks.
-
Stainless Steel Housing Construction: SUS316L body supports corrosion resistance in harsh environments.
-
IP67/IP69K Protection Rating: Designed for washdown and oil-resistant industrial installations.
The E3ZM-CT61 delivers the reliability and precision required for long-range photoelectric detection in harsh industrial automation environments.
