E5ZE-8AQHD1TCB-V2 | Omron Temperature Controller 24 VDC PID DeviceNet Multi-Sensor
- Regular price
- $812.00
- Sale price
- $812.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: E5ZE-8AQHD1TCB-V2
Description
The Omron E5ZE-8AQHD1TCB-V2 Temperature Controller is an advanced multi-input process controller designed for precise temperature regulation in industrial systems. It supports a wide range of thermocouple types and offers both solid-state and external SSR voltage outputs for flexible control configurations. Operating on 24 VDC, the unit features PID and on/off control with integrated DeviceNet communication for system integration and diagnostics.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Process Control Equipment |
| Part Number | E5ZE-8AQHD1TCB-V2 |
| Subcategory | Temperature Controllers |
| Series | E5ZE Series |
| Type | Temperature Controller |
| Input Types | Thermocouples (B, E, J, K, L, N, PLII, R, S, T, U, W) |
| Input Range | -200°C to 2300°C |
| Control Method | On/Off, Proportional (PID) |
| Output Type | Solid State (3), Voltage (External SSR) |
| Communication Interface | DeviceNet |
| Supply Voltage | 24 VDC |
| Mounting Type | Chassis Mount |
| Termination Style | Screw Terminal |
| Protection Rating | IP00 |
| Features | Heater Fault Detection, Sensor Fault Detection |
| Display Type | Digital (model-dependent) |
| Control Channels | Single Loop |
| Configuration | Modular / Panel-Embedded System |
| Enclosure | Metal or Reinforced Resin (chassis-mount type) |
| Application | Industrial Temperature and Process Control |
| Weight | Approx. 1.1 lbs |
Information About E5ZE-8AQHD1TCB-V2
The E5ZE-8AQHD1TCB-V2 belongs to the Omron E5ZE Series, a line of multi-loop and single-loop temperature controllers engineered for high accuracy and industrial reliability. This model provides universal thermocouple input compatibility, supporting Type B, E, J, K, L, N, PLII, R, S, T, U, and W sensors with a range of -200°C to 2300°C. It offers multiple solid-state outputs, external SSR control capability, and full PID tuning for stable process regulation. The controller also features heater and sensor fault detection and communicates via DeviceNet, allowing centralized control and monitoring across industrial automation networks.
Key Features:
- Wide Sensor Compatibility: Accepts multiple thermocouple types for flexible application support.
- High Temperature Range: Operates from -200°C to 2300°C for extreme process environments.
- Advanced Control Modes: Offers On/Off and PID proportional control for precise temperature management.
- Multiple Output Options: Includes solid-state outputs and voltage output for external SSRs.
- DeviceNet Communication: Enables networked control, monitoring, and configuration via industrial fieldbus.
- Fault Detection: Built-in heater and sensor fault diagnostics enhance system safety.
- Compact Chassis Mount Design: Saves panel space while providing robust mounting stability.
- Industrial Durability: Rated IP00, suitable for installation within protected control cabinets.
The E5ZE-8AQHD1TCB-V2 delivers the reliability and precision required for high-performance temperature control in automated industrial processes.
