E6F-AG5C-C | Omron Absolute Rotary Encoder 256 Resolution Gray Code Output NPN 12–24VDC IP65 60mm Housing
- Regular price
- $514.00
- Sale price
- $514.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: E6F-AG5C-C
Description
The Omron E6F-AG5C-C is an absolute rotary encoder designed for precise position feedback in industrial automation and motion control systems. The E6F-AG5C-C provides 256 pulses per rotation with Gray code output and an NPN open-collector interface for controller integration. It is built in a compact 60 mm housing with a 10 mm shaft for reliable rotational sensing applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron Automation and Safety |
| Category | Automation Control Modules |
| Part Number | E6F-AG5C-C |
| Subcategory | Absolute Rotary Encoders |
| Encoder Type | Absolute Encoder |
| Series | E6F-A Series |
| Construction Size | 60 mm Housing Diameter |
| Resolution per Rotation | 256 Positions (8-Bit) |
| Output Code | Gray Code |
| Output Type | NPN Open Collector |
| Power Supply Voltage | 12–24 VDC |
| Shaft Diameter | 10 mm |
| Connection Method | System Connector |
| Cable Length | 2 m Prewired Cable |
| Ingress Protection Rating | IP65 |
| Compatible Applications | Cam Positioners, PLC Feedback Systems |
| Weight | 1.10 lbs |
Information About E6F-AG5C-C
The E6F-AG5C-C is part of the Omron E6F-A series of absolute encoders engineered for accurate rotational position detection in automation equipment. It features an 8-bit Gray code output format that supports stable signal transmission for cam positioners and PLC-compatible control systems. The encoder operates on a 12–24 VDC power supply and uses an NPN output stage suitable for industrial sensing circuits. With a prewired 2 m cable and IP65-rated construction, it is designed for panel and machine-mounted environments requiring durable rotary feedback technology.
Key Features:
-
Absolute Rotary Encoder Design: Provides direct position feedback without loss of reference after power cycling.
-
256 Resolution per Rotation: Supports 8-bit absolute position encoding for machine control accuracy.
-
Gray Code Output Format: Ensures reliable position data transmission with minimized transition errors.
-
NPN Open-Collector Output Type: Compatible with industrial PLC and cam positioner input circuits.
-
12–24 VDC Power Supply Range: Designed for standard low-voltage automation control systems.
-
60 mm Compact Encoder Housing: Space-efficient construction for industrial machinery installations.
-
10 mm Shaft Diameter Interface: Supports direct mechanical coupling to rotating equipment.
-
Prewired System Connector Cable: Includes a 2 m connection cable for simplified installation.
The E6F-AG5C-C delivers the reliability and precision required for absolute rotary position sensing in industrial automation systems.
