Eaton ED3150W Series C 150A 3-Pole Molded Case Circuit Breaker
- Regular price
- $425.00
- Sale price
- $425.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ED3150W
Description
The Eaton ED3150W is a Series C F-frame molded case circuit breaker designed for circuit protection in industrial and commercial electrical distribution systems. This three-pole complete breaker is rated at 150 A, 240 VAC/125 VDC and uses fixed thermal and fixed magnetic trip protection with a 65 kAIC interrupt rating at 240 VAC.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breakers |
| Part Number | ED3150W |
| Subcategory | Molded Case Circuit Breakers |
| Series | Series C |
| Product Type | Complete Molded Case Circuit Breaker |
| Circuit Breaker Type | ED |
| Frame | F-Frame |
| Number of Poles | 3 |
| Amperage Rating | 150 A |
| Voltage Rating | 240 VAC, 125 VDC |
| Trip Type | T186, Fixed Thermal / Fixed Magnetic |
| Interrupt Rating | 65 kAIC at 240 VAC |
| Frequency Rating | 50/60 Hz |
| Terminals | Without Terminals |
| Certification | UL Listed |
| Dimensions | 6 × 4.13 × 3.38 in (H × W × D) |
| UPC | 786679455623 |
| Weight | 4.15 lbs |
Information About ED3150W
The ED3150W is an Eaton Series C complete molded case circuit breaker built on the F-frame platform with an ED breaker configuration. It uses a T186 fixed thermal and fixed magnetic trip system to provide overcurrent and short-circuit protection in compatible electrical distribution equipment. The three-pole breaker operates at up to 240 VAC or 125 VDC, with a 50/60 Hz frequency rating for AC applications and a 65 kAIC interrupt rating at 240 VAC. The unit is UL Listed and supplied without terminals for installation according to the requirements of the associated electrical system.
Key Features:
- 150 A Rating: Provides a rated current capacity of 150 amperes for compatible electrical circuits.
- Three-Pole Configuration: Controls and protects three conductors within applicable power distribution systems.
- Dual Voltage Rating: Rated for operation at 240 VAC and 125 VDC.
- 65 kAIC Interrupt Rating: Provides an interrupting capacity of 65 kAIC at 240 VAC.
- Fixed Trip Protection: Uses fixed thermal and fixed magnetic trip characteristics for circuit protection.
- F-Frame Construction: Built on Eaton's Series C F-frame molded case circuit breaker platform.
- 50/60 Hz Compatibility: Supports standard 50 Hz and 60 Hz AC electrical systems.
- UL Listed: Certified for applicable requirements under its UL listing.
The ED3150W delivers the reliability and precision required for overcurrent and short-circuit protection in industrial and commercial electrical distribution systems.
