Eaton EGH3020FFB Series G 20A 3-Pole Molded Case Circuit Breaker Bolt-On
- Regular price
- $566.00
- Sale price
- $566.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: EGH3020FFB
Description
The Eaton EGH3020FFB is a Series G molded case circuit breaker designed to provide dependable overcurrent protection for commercial and industrial electrical distribution systems. Eaton part number EGH3020FFB features a 20 A rating, three-pole configuration, and a thermal-magnetic trip mechanism for accurate fault detection. Its bolt-on design and high interrupting capacity make it suitable for panelboard and switchgear installations requiring reliable circuit protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | EGH3020FFB |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Molded case circuit breaker |
| Series | Series G |
| Circuit Breaker Type | EG |
| Frame | EG |
| Circuit Breaker Frame Type | Complete breaker |
| Amperage Rating | 20 A |
| Voltage Rating | 600Y/347 Vac |
| Trip Type | T186 |
| Number of Poles | Three-pole |
| Frequency Rating | 50/60 Hz |
| Terminals | Bolt-on |
| Interrupt Rating | 65 kAIC at 480 Vac |
| Additional Interrupt Ratings | 35 kAIC at 600Y/347 Vac; 100 kAIC at 240 Vac |
| Certifications | UL Listed; CSA Certified; IEC Rated |
| Compliance | CE Marked |
| Product Dimensions (L × W × H) | 2.99 × 3 × 5.5 in |
| Warranty | Eaton Selling Policy 25-000 |
| Weight | 2.9 lb |
Information About EGH3020FFB
The EGH3020FFB is a complete molded case circuit breaker from Eaton’s Series G product line, engineered for high-performance electrical protection. Built on the EG frame platform, it incorporates a T186 trip unit that provides thermal overload and instantaneous magnetic protection against short-circuit faults. The breaker uses bolt-on terminals to ensure secure mounting and electrical connections within compatible panelboards. With certifications including UL Listed, CSA Certified, and IEC Rated along with CE marking, it meets global safety and reliability standards for electrical protection devices.
Key Features:
- 20 Amp Current Rating: Provides reliable protection for branch circuits and electrical distribution systems.
- Series G Breaker Platform: Built on Eaton’s proven Series G design for durability and dependable protection.
- T186 Thermal-Magnetic Trip Unit: Combines thermal overload and magnetic short-circuit protection.
- High Interrupting Capacity: Rated up to 65 kAIC at 480 Vac for reliable fault current interruption.
- Three-Pole Configuration: Suitable for three-phase power distribution systems.
- Bolt-On Terminal Design: Ensures secure installation and strong electrical connections in panelboards.
- Wide Voltage Compatibility: Rated for systems up to 600Y/347 Vac.
- Global Safety Certifications: UL Listed, CSA Certified, IEC Rated, and CE Marked.
The EGH3020FFB delivers the reliability and precision required for protecting commercial and industrial electrical distribution circuits.
