Eaton EGH3090FFB Series G 90A 3-Pole Molded Case Circuit Breaker Bolt-On
- Regular price
- $899.00
- Sale price
- $899.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: EGH3090FFB
Description
The Eaton EGH3090FFB is a Series G molded case circuit breaker designed to provide dependable overcurrent protection for commercial and industrial electrical distribution systems. Eaton part number EGH3090FFB features a 90 A rating, three-pole configuration, and high interrupting capacity to protect circuits from overload and short-circuit faults. Its bolt-on design and robust construction ensure reliable integration within panelboards and switchgear assemblies.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | EGH3090FFB |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Molded Case Circuit Breaker |
| Series | Series G |
| Circuit Breaker Type | EG |
| Frame | EG |
| Circuit Breaker Frame Type | Complete breaker |
| Amperage Rating | 90 A |
| Voltage Rating | 600Y/347 Vac |
| Trip Type | T186 |
| Number of Poles | Three-pole |
| Frequency Rating | 50/60 Hz |
| Terminals | Bolt-on |
| Interrupt Rating | 65 kAIC at 480 Vac |
| Interrupt Rating (Additional) | 35 kAIC at 600Y/347 Vac; 100 kAIC at 240 Vac |
| Certifications | UL Listed; CSA Certified; IEC Rated |
| Compliance | CE Marked |
| Product Dimensions (L × W × H) | 2.99 × 3 × 5.5 in |
| Warranty | Eaton Selling Policy 25-000 |
| Weight | 2.91 lb |
Information About EGH3090FFB
The EGH3090FFB is a complete molded case circuit breaker from Eaton’s Series G product family, engineered for high-performance circuit protection in demanding electrical environments. Built on the EG frame platform, it uses a T186 thermal-magnetic trip unit that responds accurately to both overload and short-circuit conditions. The breaker is designed for bolt-on installation, allowing secure mounting in compatible electrical distribution panels. With certifications including UL Listed, CSA Certified, and IEC ratings, along with CE compliance, it meets international safety and performance standards.
Key Features:
- 90 Amp Current Rating: Provides reliable overcurrent protection for feeder and branch circuits in commercial and industrial systems.
- Series G Circuit Breaker Platform: Built on Eaton’s proven Series G architecture for durability and consistent electrical protection.
- T186 Thermal-Magnetic Trip Unit: Ensures accurate response to overload and short-circuit conditions.
- High Interrupting Capacity: Rated up to 65 kAIC at 480 Vac for dependable fault interruption.
- Three-Pole Configuration: Designed for protection of three-phase electrical distribution circuits.
- Bolt-On Terminal Design: Allows secure installation and reliable electrical connections in panelboards.
- Wide Voltage Compatibility: Rated for 600Y/347 Vac systems commonly used in commercial facilities.
- Global Certification Compliance: UL Listed, CSA Certified, IEC Rated, and CE Marked.
The EGH3090FFB delivers the reliability and precision required for protecting power distribution circuits in commercial, industrial, and institutional electrical systems.
