Eaton IQA6610 IQ Analyzer 6610 Power Quality Analyzer with Waveform Capture and Harmonic Analysis
- Regular price
- $7,495.00
- Sale price
- $7,495.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: IQA6610
Description
The Eaton IQA6610 IQ analyzer 6610 is an advanced power quality monitoring device designed for detailed electrical system analysis and energy measurement. It provides sub-cycle voltage disturbance capture and waveform display for precise diagnostics of power events. This analyzer is widely used in industrial and commercial facilities requiring high-accuracy monitoring and power quality assessment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Power Monitoring |
| Part Number | IQA6610 |
| Subcategory | Power Quality Analyzers |
| Product Type | IQ Analyzer 6610 |
| Accuracy Standard | ANSI C12.20 (0.2) |
| Memory | 90 KB |
| Waveform Sampling Rate | 128 samples per cycle |
| Harmonic Measurement | Up to 50th harmonic |
| THD Measurement | Current and Voltage to 50th |
| Voltage Measurement | Phase, Neutral-Ground |
| Energy Measurement | 4 Quadrant Energy |
| Frequency Range | Standard Power Frequency Monitoring |
| Power Quality Analysis | K-Factor, Crest Factor, ITIC Curve |
| Waveform Capture | Threshold/Input Triggered |
| Data Logging | Event Log with Time/Date Stamp |
| Communication | Modbus RTU (RS-485), INCOM |
| Display | Local/Remote Graphic Display |
| I/O Capability | Programmable Inputs, Relay Outputs, Analog I/O |
| Mounting Type | Panel Mount |
| Dimensions | 13 x 9.25 x 8.5 in |
| Weight | 7 lb |
Information About IQA6610
The IQA6610 is part of Eaton’s IQ analyzer series, engineered to deliver comprehensive power quality monitoring and energy analysis in complex electrical systems. It features a separate source power module and supports high-resolution waveform capture with sub-cycle voltage distribution analysis. The unit provides revenue-grade accuracy compliant with ANSI C12.20 standards, making it suitable for critical measurement applications. With integrated communication protocols such as Modbus RTU and INCOM, the analyzer enables seamless integration into energy management and automation systems.
Key Features:
- Revenue-Grade Accuracy: Complies with ANSI C12.20 (0.2) standards for precise energy measurement
- Sub-Cycle Voltage Capture: Detects and records voltage disturbances with high-resolution waveform analysis
- Harmonic Analysis Capability: Measures total harmonic distortion and individual harmonics up to the 50th order
- Waveform Sampling Rate: Captures waveforms at 128 samples per cycle for detailed power quality analysis
- Advanced Data Logging: Includes event logging with time and date stamping for system diagnostics
- Multi-Protocol Communication: Supports Modbus RTU (RS-485) and INCOM for integration with monitoring systems
- Comprehensive Instrumentation: Measures energy, power factor, demand, and phase parameters across systems
- Flexible I/O Configuration: Includes programmable inputs, relay outputs, and analog interfaces for control applications
The IQA6610 delivers the reliability and precision required for advanced power quality analysis, energy monitoring, and electrical system diagnostics in industrial and commercial environments.
