JGE3200FAG | Eaton Series G 200A 3-Pole Molded Case Circuit Breaker
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: JGE3200FAG
Description
The Eaton JGE3200FAG is a molded case circuit breaker designed to provide dependable protection against overloads and short circuits in commercial and industrial power distribution systems. This Eaton part number JGE3200FAG features a three-pole configuration with a 200 amp rating and supports operation up to 600 VAC. As part of Eaton’s Series G breaker platform, it offers fixed thermal and adjustable magnetic trip protection for reliable system performance.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | JGE3200FAG |
| Subcategory | Molded Case Circuit Breaker |
| Series | Series G |
| Frame Type | JG Frame |
| Breaker Type | Molded Case Circuit Breaker |
| Number of Poles | 3 Pole |
| Current Rating | 200 A |
| Voltage Rating | 600 VAC |
| Trip Type | T185 (Fixed Thermal, Adjustable Magnetic) |
| Interrupt Rating | 65 kAIC @ 240 VAC; 25 kAIC @ 480 VAC; 18 kAIC @ 600 VAC |
| Frequency Rating | 50–60 Hz |
| Terminal Type | Line and Load |
| Mounting Hardware | Metric |
| Rating | 80% Rated |
| Certifications | UL Listed, CSA Certified, IEC Rated, CE Marked |
| Dimensions (L×W×H) | 3.57 × 4.13 × 4.13 in |
| Weight | 6 lb |
Information About JGE3200FAG
The JGE3200FAG is part of Eaton’s Series G family of molded case circuit breakers, developed to deliver durable protection in modern electrical distribution equipment. It uses a JG frame design with a T185 trip unit that combines fixed thermal protection with adjustable magnetic trip capability to respond quickly to fault conditions. The breaker includes line and load terminals for secure electrical connections and is designed for installation in panelboards, switchgear, and industrial control systems. With certifications including UL, CSA, and IEC along with CE marking, the breaker meets international safety standards for industrial power protection.
Key Features:
- 200 Amp Current Rating: Provides dependable overcurrent protection for medium-capacity power distribution circuits.
- Three-Pole Configuration: Designed for balanced protection of three-phase electrical systems.
- Series G Platform: Part of Eaton’s established molded case circuit breaker family for industrial applications.
- Fixed Thermal, Adjustable Magnetic Trip: Allows reliable overload protection with adjustable short-circuit response.
- High Interrupting Capacity: Rated up to 65 kAIC at 240 VAC for strong short-circuit protection.
- JG Frame Construction: Durable molded case design suitable for panelboards and switchgear installations.
- International Certifications: UL listed, CSA certified, IEC rated, and CE marked for global compliance.
- Line and Load Terminals: Supports secure electrical connections in industrial distribution equipment.
The JGE3200FAG delivers the reliability and precision required for protecting commercial and industrial electrical distribution circuits.
