JGE3225FAG | Eaton Series G 225A 3-Pole Molded Case Circuit Breaker 600VAC
- Regular price
- $933.00
- Sale price
- $933.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: JGE3225FAG
Description
The Eaton JGE3225FAG is a molded case circuit breaker designed to provide reliable overcurrent protection in commercial and industrial electrical distribution systems. This Eaton part number JGE3225FAG features a 225 amp rating with a three-pole configuration and supports systems operating up to 600 Vac. Built on the Eaton Series G JG frame platform, it delivers dependable thermal-magnetic protection for panelboards, switchboards, and industrial equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | JGE3225FAG |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Molded Case Circuit Breaker |
| Series | Series G |
| Circuit Breaker Type | JG |
| Frame Size | JG Frame |
| Number of Poles | Three-pole |
| Amperage Rating | 225 A |
| Voltage Rating | 600 Vac |
| Trip Type | T185 Thermal-Magnetic |
| Frequency Rating | 50–60 Hz |
| Interrupt Rating | 65 kAIC @ 240 Vac |
| Interrupt Rating (480V) | 25 kAIC @ 480 Vac |
| Interrupt Rating (600V) | 18 kAIC @ 600 Vac |
| Terminals | Line and Load |
| Mounting Hardware | Metric |
| Certifications | UL Listed, CSA Certified, IEC Rated |
| Dimensions (L × W × H) | 3.57 × 4.13 × 4.13 in |
| Weight | 6 lb |
Information About JGE3225FAG
The JGE3225FAG is a complete molded case circuit breaker from Eaton’s Series G product family, engineered for robust circuit protection in low-voltage power distribution networks. It incorporates a fixed thermal and adjustable magnetic trip system (T185) that responds to overloads and short-circuit conditions to safeguard electrical infrastructure. The breaker is built on the JG frame platform and uses line-and-load terminals for flexible installation in switchboards and distribution assemblies. Certified under UL, CSA, and IEC standards, the device is suitable for global industrial and commercial installations requiring reliable circuit interruption and protection.
Key Features:
- 225 Amp Current Rating: Provides dependable overcurrent protection for circuits rated up to 225 A.
- Series G JG Frame Platform: Designed within Eaton’s Series G molded case breaker family for industrial durability.
- Thermal-Magnetic Trip System: T185 trip unit delivers reliable overload and short-circuit protection.
- Three-Pole Configuration: Suitable for protecting three-phase power distribution systems.
- High Interrupting Capacity: Rated up to 65 kAIC at 240 Vac and 25 kAIC at 480 Vac.
- 600 Vac Voltage Rating: Supports high-voltage commercial and industrial electrical networks.
- Line and Load Terminals: Allows straightforward installation and secure wiring connections.
- Global Compliance Certifications: UL Listed, CSA Certified, and IEC Rated for international applications.
The JGE3225FAG delivers the reliability and precision required for protecting industrial power distribution systems and commercial electrical infrastructure.
