Eaton JGS3200FAG Series G 200A 3-Pole Molded Case Circuit Breaker 600V
- Regular price
- $1,222.00
- Sale price
- $1,222.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: JGS3200FAG
Description
The Eaton JGS3200FAG is a Series G molded case circuit breaker designed to provide dependable overcurrent protection for commercial and industrial power distribution systems. Eaton part number JGS3200FAG features a 200 A rating and a three-pole configuration with a thermal-magnetic trip mechanism to detect overload and short-circuit faults. Its robust construction and high interrupting capacity ensure reliable performance in demanding electrical installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | JGS3200FAG |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Molded case circuit breaker |
| Series | Series G |
| Circuit Breaker Type | JG |
| Frame | JG |
| Circuit Breaker Frame Type | Complete breaker |
| Amperage Rating | 200 A |
| Voltage Rating | 600 Vac |
| Trip Type | T185 |
| Number of Poles | Three-pole |
| Terminals | Line and load |
| Mounting Hardware | Metric |
| Interrupt Rating | 18 kAIC at 600 Vac |
| Additional Interrupt Ratings | 35 kAIC at 480 Vac; 40 kAIC at 415 Vac; 85 kAIC at 240 Vac |
| Certifications | UL Listed; CSA Certified; IEC Rated |
| Compliance | CE Marked |
| Product Dimensions (L × W × H) | 3.57 × 4.13 × 4.13 in |
| Weight | 6 lb |
Information About JGS3200FAG
The JGS3200FAG is a complete molded case circuit breaker from Eaton’s Series G circuit protection lineup, engineered for reliable operation in electrical distribution equipment. Built on the JG frame platform, it incorporates a T185 thermal-magnetic trip unit that responds to both sustained overloads and instantaneous fault currents. The breaker includes line and load terminals for secure electrical connections and supports metric mounting hardware for installation flexibility. Certified to UL, CSA, and IEC standards with CE compliance, it is suitable for use in a wide range of global industrial and commercial electrical systems.
Key Features:
- 200 Amp Current Rating: Designed to protect feeder and branch circuits in industrial and commercial power systems.
- Series G Circuit Breaker Platform: Built on Eaton’s proven Series G architecture for dependable electrical protection.
- T185 Thermal-Magnetic Trip Unit: Provides accurate response to overload and short-circuit conditions.
- High Interrupting Capacity: Rated up to 85 kAIC at 240 Vac for safe interruption of high fault currents.
- Three-Pole Configuration: Suitable for protecting three-phase power distribution circuits.
- Line and Load Terminals: Ensures secure electrical connections and simplified installation.
- Wide Voltage Compatibility: Rated for systems up to 600 Vac.
- Global Safety Certifications: UL Listed, CSA Certified, IEC Rated, and CE Marked for international compliance.
The JGS3200FAG delivers the reliability and precision required for protecting electrical distribution circuits in commercial and industrial power systems.
