Eaton MTK1000 Circuit Breaker Trip Unit Test Kit for Diagnostic Testing and Maintenance
- Regular price
- $3,990.00
- Sale price
- $3,990.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: MTK1000
Description
The Eaton MTK1000 is a circuit breaker trip unit test kit designed to verify the operational performance of electronic trip units used in molded case and low-voltage power circuit breakers. Eaton part number MTK1000 enables technicians to simulate trip conditions and confirm proper breaker response during commissioning, maintenance, and troubleshooting. This portable diagnostic tool helps ensure electrical protection systems operate reliably in industrial and commercial installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | MTK1000 |
| Subcategory | Circuit Breaker Accessory |
| Product Type | Circuit Breaker Trip Unit Test Kit |
| Application | Testing electronic trip units in circuit breakers |
| Compatibility | Eaton molded case and low-voltage power circuit breakers |
| Function | Trip unit diagnostic and verification testing |
| Testing Capability | Simulated trip signal generation |
| Use Case | Maintenance, commissioning, troubleshooting |
| Portability | Field service diagnostic kit |
| Manufacturer Status | Discontinued by manufacturer |
| Weight | 8 lb |
Information About MTK1000
The MTK1000 is a specialized testing accessory manufactured by Eaton for evaluating the functionality of electronic trip units installed in circuit breakers. It allows technicians to perform controlled testing of breaker protection mechanisms without removing the breaker from service. The kit provides simulated trip signals and diagnostic capability to confirm correct operation of protection functions such as overload and short-circuit response. Although discontinued by the manufacturer, it remains widely used for maintaining legacy Eaton circuit breaker systems and ensuring continued operational reliability.
Key Features:
- Trip Unit Diagnostic Testing: Allows verification of electronic trip unit functionality in circuit breakers.
- Maintenance and Commissioning Tool: Supports system commissioning, routine inspection, and troubleshooting procedures.
- Portable Test Equipment: Compact design enables technicians to easily transport and use the kit in field environments.
- Simulated Trip Signal Capability: Generates controlled signals to test breaker response and protection accuracy.
- Compatibility with Eaton Breakers: Designed for use with Eaton electronic trip units in molded case and low-voltage power breakers.
- System Reliability Verification: Helps confirm protection devices will operate correctly during electrical fault conditions.
- Service and Maintenance Support: Enables preventive maintenance of circuit protection equipment.
The MTK1000 delivers the reliability and precision required for testing and verifying circuit breaker protection systems.
