Eaton PDG23M0100E3RL Power Defense 100A 3-Pole Molded Case Circuit Breaker
- Regular price
- $1,775.00
- Sale price
- $1,775.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: PDG23M0100E3RL
Description
The Eaton PDG23M0100E3RL is a Power Defense molded case circuit breaker designed to provide dependable overcurrent protection for commercial and industrial electrical systems. Eaton part number PDG23M0100E3RL features a 100 A rating, three-pole configuration, and high interrupt capacity to protect electrical feeders and equipment from overloads and short circuits. Its compact frame and advanced trip technology support reliable performance in modern power distribution applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | PDG23M0100E3RL |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Power Defense Molded Case Circuit Breaker |
| Series | Power Defense PD2 Global |
| Circuit Breaker Type | PD2 Global |
| Circuit Breaker Frame Type | Complete breaker |
| Frame | Frame 2 |
| Amperage Rating | 100 A |
| Trip Rating | 100 A |
| Number of Poles | Three-pole |
| Voltage Rating | 600 Vac |
| Trip Type | T285 |
| Interrupt Rating | 65 kAIC at 480 Vac |
| Interrupt Rating Range | 100 kAIC @240V (UL); 22 kAIC Icu @250 Vdc |
| Terminals | Standard Terminals Load Only |
| Certifications | UL 489; IEC 60947-2; CSA; CCC Marked |
| Compliance | RoHS Compliant |
| Product Dimensions (L × W × H) | 88.9 × 104.6 × 152.4 mm |
| Warranty | Eaton Selling Policy 25-000 |
| Weight | 1.82 kg |
Information About PDG23M0100E3RL
The PDG23M0100E3RL is a complete molded case circuit breaker from Eaton’s Power Defense PD2 Global series, engineered for reliable circuit protection in demanding electrical installations. It utilizes a T285 electronic trip unit to provide accurate detection and interruption of fault conditions. Built on the Frame 2 platform, the breaker is designed for three-phase electrical systems used in commercial facilities and industrial equipment. With global certifications including UL 489, IEC 60947-2, CSA, and CCC, the device meets international safety and performance standards.
Key Features:
- 100 Amp Current Rating: Provides dependable protection for branch circuits and feeder applications.
- Power Defense PD2 Global Design: Engineered using Eaton’s advanced circuit protection platform.
- T285 Electronic Trip Unit: Offers precise overload and short-circuit protection.
- Three-Pole Configuration: Suitable for protecting three-phase electrical distribution systems.
- High Interrupting Capacity: Rated up to 65 kAIC at 480 Vac for safe interruption of high fault currents.
- Compact Frame 2 Construction: Optimized size for efficient installation in panels and switchgear.
- Load-Side Standard Terminals: Designed for secure load-side electrical connections.
- Global Certifications: Compliant with UL, IEC, CSA, and CCC standards for international use.
The PDG23M0100E3RL delivers the reliability and precision required for protecting industrial and commercial power distribution circuits.
