Eaton PDG62M1600E4RN Power Defense 1600A 2-Pole Molded Case Circuit Breaker
- Regular price
- $6,299.00
- Sale price
- $6,299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: PDG62M1600E4RN
Description
The Eaton PDG62M1600E4RN is a Power Defense molded case circuit breaker designed to deliver high-capacity overcurrent protection in industrial and commercial power distribution systems. Eaton part number PDG62M1600E4RN features a 1600 A rating, advanced electronic trip protection, and a robust frame designed for demanding electrical applications. Its high interrupting capacity and global certification compliance ensure dependable protection for critical electrical infrastructure.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | PDG62M1600E4RN |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Molded case circuit breaker |
| Series | Power Defense |
| Circuit Breaker Type | PD6 Global |
| Frame | 6 |
| Circuit Breaker Frame Type | Complete breaker |
| Class | Class A |
| Amperage Rating | 1600 A |
| Trip Rating | 1600 A |
| Trip Type | T284 |
| Voltage Rating | 600 Vac |
| Number of Poles | Two-pole |
| Interrupt Rating | 65 kAIC at 480 Vac |
| Additional Interrupt Ratings | 100 kAIC @240V (UL); 35 kAIC @600/347V (UL); multiple IEC ratings |
| Terminals | No terminals |
| Certifications | UL 489; CSA; IEC 60947-2; CCC Marked |
| Compliance | RoHS Compliant |
| Product Dimensions (L × W × H) | 247.7 × 393.7 × 406.4 mm |
| Warranty | Eaton Selling Policy 25-000 |
| Weight | 43.091 kg |
Information About PDG62M1600E4RN
The PDG62M1600E4RN is a complete molded case circuit breaker from Eaton’s Power Defense PD6 Global series, engineered for large-scale power distribution and high-load electrical systems. Built on the Frame 6 platform, it incorporates a T284 electronic trip unit that provides precise detection and response to overload and short-circuit conditions. The breaker operates at voltages up to 600 Vac and is designed without terminals to allow flexible installation with appropriate connection hardware. With certifications including UL 489, CSA, IEC 60947-2, and CCC marking, it meets international safety and performance standards for industrial electrical protection.
Key Features:
- 1600 Amp Current Rating: Designed for high-capacity feeder and distribution circuit protection in industrial systems.
- Power Defense PD6 Global Platform: Built on Eaton’s advanced circuit protection architecture for large electrical systems.
- T284 Electronic Trip Unit: Provides precise monitoring and response to overload and fault conditions.
- High Interrupting Capacity: Rated up to 65 kAIC at 480 Vac for reliable fault current interruption.
- Two-Pole Configuration: Suitable for specialized high-current power distribution applications.
- Flexible Terminal Configuration: Supplied without terminals to support custom connection configurations.
- Global Compliance Certifications: UL 489, CSA, IEC 60947-2, and CCC certified for international installations.
- Heavy-Duty Frame Design: Frame 6 construction supports high-current industrial power systems.
The PDG62M1600E4RN delivers the reliability and precision required for protecting high-capacity industrial and commercial power distribution circuits.
