ebm-papst A2S130-AB03-11 A2S130 230VAC 3250 RPM Axial Cooling Fan
- Regular price
- $110.00
- Sale price
- $110.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: A2S130-AB03-11
Description
The ebm-papst A2S130-AB03-11 is an AC axial cooling fan designed to provide forced-air circulation and thermal management for electrical and industrial equipment. Operating from a 230 VAC supply at speeds up to 3250 RPM, it combines a steel housing, ball-bearing construction, and IP44 protection for equipment cooling applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ebm-papst |
| Category | Thermal Management |
| Part Number | A2S130-AB03-11 |
| Subcategory | Axial Cooling Fans |
| Series | A2S130 |
| Fan Type | Axial Fan |
| Current Type | AC |
| Operating Supply Voltage | 230 VAC |
| Nominal Voltage Range | 220–240 VAC |
| Current | 0.30 A |
| Power Rating | 45 W |
| Speed | 3250 RPM |
| Bearing Type | Ball Bearing |
| Housing Material | Steel |
| IP Rating | IP44 |
| Dimensions | 138 × 138 × 57 mm |
| Wiring | 2 Wires |
| Weight | 1 kg |
Information About A2S130-AB03-11
The A2S130-AB03-11 is an axial fan from the ebm-papst A2S130 series, built for AC-powered cooling and ventilation systems. Its construction incorporates a steel housing and ball-bearing system for mechanically supported continuous rotational operation. The fan is compatible with nominal 220–240 VAC applications, with 230 VAC specified as its operating supply voltage, making it suitable for control cabinets, electrical equipment, machinery, and similar forced-air cooling installations. Its two-wire connection, IP44 protection rating, and operating speed of up to 3250 RPM provide a straightforward configuration for integration into industrial thermal-management systems.
Key Features:
- Axial Fan Design: Produces direct airflow for cooling and ventilation of electrical and industrial equipment.
- AC Supply Operation: Designed for nominal 220–240 VAC operation, with a specified operating supply voltage of 230 VAC.
- 3250 RPM Speed: Provides high-speed forced-air movement for thermal management applications.
- Ball Bearing System: Uses ball bearings to support stable fan rotation during operation.
- Steel Housing: Incorporates metal construction for structural support in industrial installations.
- IP44 Protection: Provides protection against solid objects larger than 1 mm and splashing water.
- Compact Construction: Approximately 138 mm wide by 138 mm high by 57 mm deep according to the supplied manufacturer data.
- Two-Wire Connection: Uses a simple two-wire electrical connection for AC power integration.
The A2S130-AB03-11 delivers the reliability and precision required for forced-air cooling and thermal management in industrial electrical equipment.
