ECC-CE4 | Fire-Lite Distributed Audio Zone Expander, 4 Supervised Circuits
- Regular price
- $614.00
- Sale price
- $614.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: ECC-CE4
Description
The Fire-Lite ECC-CE4 is a distributed audio zone expander module designed to add four additional supervised audio circuits to the ECC-50DA(E) or ECC-125DA(E) amplifiers. This compact and modular device enhances system flexibility and ensures reliable expansion of Fire-Lite emergency communication and voice evacuation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Fire-Lite Alarms by Honeywell |
| Category | Fire Safety |
| Part Number | ECC-CE4 |
| Subcategory | Audio Circuit Expander |
| Mounting Location | Inside ECC-50DA(E) or ECC-125DA(E) cabinet |
| Supported Circuits | Four audio circuits, Style Y (Class B) or Style Z (Class A) |
| Output Power | 50W of 25V audio power, expandable to 100W RMS |
| Optional Transformer | 70.7 VRMS conversion transformer available |
| Configuration | Web-based programming via ECC-50/100(E) |
| Protocol Support | System Sensor®, Wheelock®, Gentex® synchronization |
| Listings & Approvals | UL 2572, UL 864 |
| Production Status | Active |
| Unit of Measurement | Each (EA) |
| Weight | 1 lb |
Information About ECC-CE4
The ECC-CE4 is a circuit expander module built for integration within the Fire-Lite ECC-50/100(E) Emergency Command Center and its distributed amplifiers. It mounts directly inside the ECC-50DA(E) or ECC-125DA(E) cabinet, providing up to four Style Z (Class A) or Style Y (Class B) speaker circuits. With removable terminal blocks for simplified servicing and UL 2572/UL 864 compliance, the ECC-CE4 ensures seamless and code-compliant system expansion. Its design supports synchronization protocols for System Sensor, Wheelock, and Gentex notification appliances.
Key Features
- Additional Circuits: Expands ECC-50DA(E) and ECC-125DA(E) units with four supervised audio circuits.
- Flexible Wiring: Supports Style Z (Class A) or Style Y (Class B) speaker circuits.
- Easy Installation: Mounts inside the amplifier cabinet for space efficiency.
- Service-Friendly: Removable terminal blocks simplify servicing and replacement.
- Protocol Compatibility: Works with System Sensor, Wheelock, and Gentex sync protocols.
- High Power Capability: Supports up to 50W of 25V audio power, expandable to 100W RMS.
- Optional Transformer: 70.7 VRMS conversion transformer available for the primary amplifier.
- Code-Compliant: UL 2572 and UL 864 listed for mass notification and emergency voice evacuation.
The ECC-CE4 delivers the reliability and scalability required for expanding Fire-Lite emergency voice systems.
