ECS-VCM | Silent Knight Emergency Communication Voice Control Module, 100W Output
- Regular price
- $1,719.00
- Sale price
- $1,719.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: ECS-VCM
Description
The Silent Knight ECS-VCM is a voice control module for the Silent Knight Emergency Communication System, designed to manage and distribute voice messages during fire and life safety events. It provides up to 100 watts of audio power and supports multiple audio circuits for paging, evacuation, and emergency announcements.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Silent Knight |
| Category | Fire Alarm Equipment |
| Part Number | ECS-VCM |
| Subcategory | Voice Control Module |
| Series | Emergency Communication System (ECS) |
| Product Type | Voice control and audio distribution module |
| Power Output | Circuit 1: 100 W max; Circuits 2–8: 50 W max |
| Communication Interface | Six-conductor (two voice bus, four SBUS) |
| Main ECS Panel SBUS Current | Standby: 10 mA; Alarm: 10 mA |
| Battery Charging Capacity | 7–35 AH (18 AH max internal, up to 35 AH with RBB cabinet) |
| Operating Voltage | 24 VDC nominal from ECS system |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Humidity Range | 10–93% RH (non-condensing) |
| Mounting Type | Flush or surface |
| Flush Mount Dimensions | 14.05” W × 24.75” H × 3.04” D (36.08 × 62.09 × 8.07 cm) |
| Overall Dimensions | 16.0” W × 26.25” H × 4.01” D (40.06 × 66.07 × 10.05 cm) |
| Cabinet Color | Red or Black |
| Application | Voice evacuation and emergency mass notification |
| Compliance | UL listed (where applicable) |
| Weight | 4 lbs (approx.) |
Information About ECS-VCM
The ECS-VCM is part of Silent Knight’s Emergency Communication System (ECS) platform, engineered for voice evacuation and mass notification in commercial, institutional, and industrial facilities. It integrates with Silent Knight control panels through a six-conductor communication link for audio and data distribution. The module includes eight speaker circuits, delivering 100 watts on circuit one and up to 50 watts each on additional circuits, depending on configuration. Designed for flexible installation, the ECS-VCM supports flush or surface mounting and features a red or black enclosure. With a wide operating range and robust power capability, it ensures clear, intelligible voice messages during emergencies.
Key Features:
- High Power Output: Provides up to 100 watts on Circuit 1 and 50 watts on Circuits 2–8.
- Integrated Voice Control: Manages paging, evacuation, and mass notification messages.
- System Integration: Communicates with ECS panels via six-conductor voice and SBUS wiring.
- Battery Backup Support: Charges 7–35 AH batteries (up to 18 AH within cabinet).
- Environmental Range: Operates from 32°F to 120°F and 10–93% relative humidity.
- Mounting Options: Supports flush or surface mounting with red or black cabinet finish.
- Reliable Construction: Built for continuous operation in fire alarm and emergency systems.
- Scalable Design: Easily expands voice communication coverage across large buildings.
The ECS-VCM delivers the reliability and precision required for emergency voice evacuation and life safety communication.
