ED2200 | Eaton Series C F-Frame 200A 2-Pole Molded Case Circuit Breaker 240V
- Regular price
- $452.00
- Sale price
- $452.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ED2200
Description
The Eaton ED2200 is a Series C complete molded case circuit breaker engineered for reliable overcurrent protection in commercial and industrial power systems. This two-pole breaker is rated at 200 A and operates at up to 240 VAC or 125 VDC, utilizing a fixed thermal and fixed magnetic trip unit. Its F-frame construction supports dependable performance in applications requiring high interrupting capacity.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | ED2200 |
| Subcategory | Molded Case Circuit Breaker |
| Series | Series C |
| Breaker Type | ED |
| Frame Type | F-Frame |
| Breaker Configuration | Complete breaker |
| Amperage Rating | 200 A |
| Voltage Rating | 240 VAC / 125 VDC |
| Frequency Rating | 50/60 Hz |
| Number of Poles | 2 |
| Trip Type | Fixed thermal, fixed magnetic |
| Interrupt Rating | 65 kAIC at 240 VAC |
| Terminal Type | Line and load |
| Product Depth | 3.38 in |
| Product Height | 6 in |
| Product Width | 2.75 in |
| Weight | 2.9 lb |
Information About ED2200
The ED2200 is an Eaton Series C molded case circuit breaker classified within the F-frame platform. It is manufactured as a complete breaker with non-adjustable thermal and magnetic trip elements to provide consistent and predictable protection characteristics. The two-pole design supports use in single-phase and DC distribution systems operating at rated voltages. This breaker is commonly installed in industrial and commercial panels where high interrupting capacity and robust Series C construction are required.
Key Features
- Series C F-Frame Design: Built within Eaton’s Series C platform to support robust power distribution and standardized breaker integration.
- 200 Amp Continuous Rating: Suitable for feeder and main circuit protection in high-current commercial and industrial applications.
- Two-Pole Configuration: Supports protection of 240 VAC and 125 VDC circuits in a compact footprint.
- Fixed Thermal and Magnetic Trip Units: Provides stable overload and short-circuit protection without field adjustments.
- High Interrupting Capacity: Rated at 65 kAIC at 240 VAC for applications with elevated available fault current.
- Line and Load Terminals: Allows flexible installation orientation in panelboards and distribution equipment.
- Compact F-Frame Construction: Delivers high performance while maintaining space-efficient installation.
The ED2200 delivers the reliability and precision required for high-capacity circuit protection in Eaton Series C industrial and commercial electrical distribution systems.
