Part #: ED3200 Manufactured by: Eaton
Regular price
$749.00
Sale price
$749.00
Regular price
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The ED3200 is a molded case circuit breaker manufactured by Eaton as part of the Series C range. It belongs to the F-frame...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: ED3200
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Eaton
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: ED3200

Description / Specifications

Description

The ED3200 is a Eaton Series C complete molded case circuit breaker, featuring an F-frame design. It operates as a three-pole breaker with a nominal current rating of 200 A. With fixed thermal and fixed magnetic trip types, it ensures reliable protection against electrical overloads and faults. The breaker is designed for use in electrical systems with a voltage rating of 240 Vac and 125 Vdc, operating at a frequency of 50/60 Hz.



Technical Specifications

Product Name

Eaton Series C complete molded case circuit breaker

Catalog Number

ED3200

UPC

786679455142

Product Length/Depth

3.38 in

Product Height

6 in

Product Width

4.13 in

Product Weight



Amperage Rating

200 A

Voltage Rating

240 Vac, 125 Vdc

Trip Type

Fixed thermal, fixed magnetic

Circuit Breaker Type

ED

Circuit Breaker Frame Type

Complete breaker

Series

Series C

Terminals

Line and load

Frame

F

Frequency Rating

50 to 60 Hz

Interrupt Rating

65 kAIC at 240 Vac

Number of Poles

Three-pole



Information About ED3200


The ED3200 is a molded case circuit breaker manufactured by Eaton, belonging to the Series C range. It features an F-frame design and is designated as the ED model. This circuit breaker is categorized as a complete breaker, incorporating both fixed thermal and fixed magnetic trip types for protection. Designed for three-pole operation, it is capable of handling currents up to 200 A.

In terms of voltage compatibility, the ED3200 is rated for both alternating and direct current systems. It has a voltage rating of 240 VAC for alternating current and 125 VDC for direct current applications. With an interrupt rating of 65 kAIC at 240 VAC, this circuit breaker offers robust protection against overloads and short circuits, ensuring reliable performance in diverse electrical environments.

The operational frequency of the ED3200 is suitable for both 50 Hz and 60 Hz systems, making it versatile for various power grid configurations. Its F-frame design and three-pole construction contribute to its durability and suitability for industrial applications where heavy-duty electrical protection is required.







Manufacturer information

Eaton Corporation is a multinational power management company offering a diverse range of electrical, hydraulic, and aerospace solutions. Known for innovation, Eaton serves customers in various industries worldwide.

IQElectro is not an authorized distributor.
