EDB34035 | Schneider Electric Mini Circuit Breaker
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EDB34035
Description
The EDB34035 is a mini circuit breaker in the E-Frame series, specifically designed for use in Square D NF Panelboards. This breaker provides robust overload and short circuit protection, featuring a thermal-magnetic trip unit and a signal indicator to show when a trip has occurred. It is HID and HACR rated.
Technical Specifications
|
Part Number |
EDB34035 |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Range of Product |
125 A Frame EDB-EGB-EJB |
|
Product or Component Type |
Miniature circuit-breaker |
|
Device short name |
EDB |
|
Module type |
E-Frame |
|
Trip unit rating |
1800 A |
|
Line Rated Current |
35 A |
|
Maximum Operating Voltage |
480Y/277 V AC |
|
AWG gauge |
AWG 12...AWG 2/0 aluminium, AWG 14...AWG 2/0 copper |
|
Electrical connection |
Lugs aluminium |
|
Holding Current |
630 A |
|
Local signalling |
Trip indicator |
|
Mounting Mode |
Bolt-on |
|
Number of poles |
3 |
|
Number of spaces |
3 |
|
Number of spaces required |
3 |
|
Product destination |
NF panelboard |
|
Protection Type |
Short-circuit, Overload |
|
Trip unit technology |
Thermal-magnetic |
|
Breaking capacity code |
D |
|
Height |
5.66 in (143.76 mm) |
|
Width |
2.94 in (74.68 mm) |
|
Depth |
4.05 in (102.87 mm) |
|
Net Weight |
4 lb(US) (1.81 kg) |
Information About EDB34035
The EDB34035 is a miniature circuit breaker from the E-Frame series, specifically designed for use in Square D NF Panelboards. This breaker is engineered to provide reliable and efficient protection for lighting panelboards, with a focus on overload and short circuit protection.
The E-Frame breaker features a thermal-magnetic trip unit, which ensures accurate and timely response to overcurrent conditions. It is equipped with a signal indicator that alerts when a trip has occurred, enhancing safety and reliability. The breaker is HID rated, meaning it meets the requirements for high-intensity discharge lighting systems, and HACR rated, indicating it is suitable for heating, air conditioning, and refrigeration applications.
This particular model, EDB34035, has a rated current of 35A and is a 3-pole device, making it suitable for three-phase systems. It operates at a maximum voltage of 480Y/277 VAC, providing versatility for a range of electrical installations. The breaker boasts a maximum interrupt rating of 25 kA at 120 VAC, ensuring it can safely interrupt high fault currents without damage.
