EDB34040 | Schneider Electric Square D E-Frame Circuit Breaker, 40A, 3-Pole, 480Y/277VAC, 18kA, Bolt-On
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: EDB34040
Description
The Schneider Electric EDB34040 is a 40A E-Frame molded case circuit breaker engineered for lighting and branch distribution circuits in Square D NF panelboards. Rated for 480Y/277 VAC operation with an 18kA interrupting capacity, it provides dependable thermal-magnetic protection for commercial applications. Its bolt-on configuration and integrated trip indicator ensure secure installation and clear fault identification.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | EDB34040 |
| Subcategory | Molded Case Circuit Breaker E-Frame |
| Manufacturer | Schneider Electric |
| Poles | 3 |
| Amperage Rating | 40 A |
| Voltage Rating | 480Y/277 VAC |
| Interrupt Rating | 18 kA @ 480V |
| Interrupt Rating (Additional) | 25 kA @ 120/240 VAC |
| Trip Technology | Thermal Magnetic |
| Trip Indicator | Yes |
| HID / HACR Rating | Yes |
| Installation Type | Bolt-On |
| Conductor Range (Aluminum) | AWG 12–2/0 |
| Conductor Range (Copper) | AWG 14–2/0 |
| Hold Current | 630 A |
| Trip Current | 1800 A |
| Dimensions (H × W × D) | 5.66 in × 2.94 in × 4.05 in |
| Calibration Temperature | 40°C |
| Application | Lighting, HVAC, Commercial Distribution |
Information About EDB34040
The EDB34040 is part of the Square D E-Frame miniature molded case breaker family and is specifically designed for NF lighting panelboard systems. Its 3-pole arrangement supports three-phase distribution at 480Y/277 VAC, delivering stable 40-amp protection with UL and CSA certification. The breaker utilizes thermal-magnetic trip technology and includes a signal indicator for rapid identification of tripped conditions. HID and HACR ratings extend its suitability for lighting, HVAC, and motor-related applications, while aluminum lugs support conductor sizes up to 2/0 AWG for both copper and aluminum wiring.
Key Features
- E-Frame design: Tailored for Square D NF lighting and branch panelboard applications.
- 40A, 3-pole configuration: Supports three-phase circuits requiring moderate load protection.
- 480Y/277 VAC rating: Optimized for commercial lighting and distribution systems.
- 18 kA interrupting capacity: Provides strong short-circuit performance at 480V.
- Thermal-magnetic trip unit: Offers reliable overload and fault response.
- Trip indicator included: Provides clear visual indication of breaker status.
- HID & HACR rated: Suitable for lighting, HVAC, and motor control applications.
- Bolt-on installation: Ensures secure mechanical mounting in NF panelboards.
The EDB34040 delivers the reliability and precision required for commercial lighting, HVAC, and distribution circuits in modern electrical systems.
