Product Description P/N: EDH2200
Description
The Eaton EDH2200 is a 2-pole molded case circuit breaker designed to provide dependable overcurrent protection in commercial and industrial electrical systems. This breaker supports 200-amp circuits at 240VAC or 125VDC and delivers high interrupting performance for demanding applications. The EDH2200 is suitable for installations requiring a compact F-Frame device with fixed thermal-magnetic trip technology.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton / Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | EDH2200 |
| Subcategory | 2-Pole Circuit Breaker |
| Series | Series C |
| Frame Type | F-Frame |
| Amperage Rating | 200A |
| Voltage Rating | 240VAC, 125VDC |
| Poles | 2 |
| Interrupting Rating | 100kAIC @ 240VAC |
| Trip Type | Thermal-Magnetic |
| Trip Functions | Long-Time & Instantaneous |
| Connection Type | Bolt-On |
| Terminals | Load Side |
| Frequency Rating | 50–60 Hz |
| Circuit Breaker Type | EDH |
| Dimensions (H × W × D) | 6 in × 2.75 in × 3.38 in |
| Weight | 3 lb |
Information About EDH2200
The EDH2200 is a Series C molded case circuit breaker built with an F-Frame housing designed for durable operation in distribution equipment. It incorporates a fixed thermal-magnetic trip unit that supports long-time and instantaneous protection functions. The breaker is compatible with bolt-on mounting systems commonly used in panelboards and switchgear. Its UL-listed construction and load-side terminals make it suitable for both new assemblies and replacement applications.
Key Features:
- Series C Platform: Built on Eaton’s standard Series C architecture for reliable system integration.
- Fixed Thermal-Magnetic Trip: Provides overload and short-circuit protection with stable trip characteristics.
- High Interrupt Rating: Rated up to 100kAIC at 240VAC for demanding fault conditions.
- Bolt-On Connection: Ensures secure installation in panelboards and distribution equipment.
- F-Frame Construction: Compact design supports high-capacity performance in limited spaces.
- UL Listed Compliance: Verified to meet recognized electrical safety and performance standards.
- Load-Side Terminals: Enables straightforward conductor attachment for distribution circuits.
The EDH2200 delivers the reliability and precision required for molded case overcurrent protection in electrical distribution systems.
