Edwards SA-ETH Ethernet Programming and Diagnostics Module for Intelligent Fire Alarm Control Panels
- Regular price
- $518.00
- Sale price
- $518.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SA-ETH
Description
The Edwards SA-ETH is an Ethernet programming and diagnostics module designed to provide network connectivity for compatible Edwards intelligent fire alarm control panels. The Edwards SA-ETH enables remote programming, diagnostics, configuration management, and status monitoring over a standard Ethernet network, improving system maintenance and administration.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Edwards |
| Category | Safety Systems |
| Part Number | SA-ETH |
| Subcategory | Fire Alarm Communication Module |
| Product Type | Ethernet Programming and Diagnostics Module |
| Application | Network Management |
| Network Interface | 1 × RJ-45 10/100 Base-T Ethernet |
| Connector Type | RJ-45 |
| Communication Speed | 10/100 Base-T with Automatic Negotiation |
| Operating Voltage | 24 Volts Direct Current |
| Operating Current | 34 mA Typical, 41 mA Maximum |
| Mounting Type | Cabinet Mount |
| Compatible Systems | Edwards FX Series, iO64, iO1000 Fire Alarm Control Panels |
| Functions | Remote Programming, Diagnostics, Status Monitoring, Configuration Upload and Download |
| Maximum Network Cable Length | 200 ft (60 m) Category 5 Cable |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Operating Humidity | 0% to 93% Relative Humidity, Non-Condensing |
| Weight | 0.25 lb (0.11 kg) |
Information About SA-ETH
The SA-ETH is an optional management module developed for compatible Edwards intelligent fire alarm control systems, including the FX Series and iO Series control panels. It provides a standard 10/100 Base-T Ethernet interface that connects the fire alarm panel to an intranet, local area network, or compatible monitoring infrastructure. The module supports uploading and downloading panel configuration, system history, current status information, and diagnostics through compatible configuration software while simplifying commissioning and service operations. Designed for cabinet mounting, the SA-ETH installs directly onto the control panel assembly and communicates with the main control board through a ribbon cable, providing dependable network integration for life safety systems.
Key Features:
- Standard Ethernet Connectivity: Provides one 10/100 Base-T Ethernet connection for local or enterprise network integration.
- Remote Programming Support: Allows uploading and downloading of panel configuration through the network.
- Diagnostic Communications: Enables remote diagnostics, system status monitoring, and maintenance functions.
- Automatic Network Negotiation: Supports automatic speed and duplex negotiation for simplified installation.
- Direct Panel Integration: Connects directly to the main control board using a dedicated ribbon cable.
- Cabinet Mount Design: Mounts securely inside compatible Edwards fire alarm control panel enclosures.
- Configuration Utility Compatibility: Works with compatible Edwards configuration software for programming and servicing.
- Status Indicator Light Emitting Diodes: Includes dedicated indicators for link, speed, duplex, and network activity.
The SA-ETH delivers the reliability and precision required for secure network programming and diagnostics in compatible Edwards intelligent fire alarm systems.
