Edwards Signaling 116EXMSTR-N5 Explosionproof Xenon Strobe Light 120 VAC Red Lens NEMA 3R/4X
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 116EXMSTR-N5
Description
The Edwards Signaling 116EXMSTR-N5 is an explosionproof xenon strobe light designed to provide high-intensity visual warning in hazardous and marine environments. Manufactured by Edwards Signaling, the 116EXMSTR-N5 operates on 120 VAC and produces an 800,000-candela red flashing signal for reliable emergency notification and equipment status indication. Its cast aluminum housing, corrosion-resistant finish, and NEMA 3R/4X enclosure ensure dependable performance in demanding industrial locations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Edwards Signaling |
| Category | Hazardous Location Signaling |
| Part Number | 116EXMSTR-N5 |
| Subcategory | Explosionproof Strobe Light |
| Series | 116 Series |
| Product Type | Explosionproof Xenon Strobe Light |
| Operating Voltage | 120 VAC |
| Frequency | 50/60 Hz |
| Operating Current | 0.1 A |
| Lamp Type | Xenon Strobe |
| Lens Color | Red |
| Flash Rate | 65 FPM |
| Peak Light Output | 800,000 cd |
| Lamp Life | 3,000 Hours |
| Housing Material | Cast Aluminum |
| Lens Material | High-Impact Glass |
| Enclosure Finish | Epoxy Powder Coated |
| Enclosure Rating | NEMA 3R/4X |
| Mounting | Pendant, Ceiling, Stanchion, Bracket (mounting bracket sold separately) |
| Special Features | Corrosion Resistant, Explosionproof, Includes Dome Guard |
| Hazardous Location Rating | Class I Div. 1 Group C, D; Class I Div. 2 Group A, B, C, D; Class II Div. 1 Group E, F, G; Class II Div. 2 Group F, G; Class III Div. 1 Group E, F, G; Class III Div. 2 Group F, G |
| Approvals | UL 1203, UL 1598A, UL 1638, cUL, CSA C22.2 |
| Application | Hazardous Locations, Marine Facilities |
| Weight | 10 lb (4.54 kg) |
Information About 116EXMSTR-N5
The 116EXMSTR-N5 is part of the Edwards Signaling 116 Series of Genesis explosionproof visual signaling devices engineered for hazardous-area applications. It features a rugged cast aluminum enclosure with an epoxy powder-coated finish and a high-impact glass dome protected by an integrated dome guard for enhanced durability. The strobe is approved for numerous Class I, II, and III hazardous locations, making it suitable for petrochemical plants, refineries, marine installations, and other severe-duty environments. It supports pendant, ceiling, stanchion, and bracket mounting, allowing flexible installation in industrial safety and emergency signaling systems.
Key Features:
- Explosionproof Construction: Designed for hazardous industrial and marine environments.
- High-Intensity Xenon Strobe: Produces 800,000 cd peak light output for excellent visibility.
- 120 VAC Operation: Operates on standard 120 VAC, 50/60 Hz power systems.
- Red Visual Signal: High-visibility red lens for emergency and warning applications.
- Corrosion-Resistant Housing: Cast aluminum enclosure with epoxy powder-coated finish.
- High-Impact Glass Dome: Durable glass lens with protective dome guard.
- Multiple Mounting Options: Supports pendant, ceiling, stanchion, and bracket mounting.
- Hazardous Location Certified: Approved for Class I, II, and III hazardous environments with NEMA 3R/4X protection.
The 116EXMSTR-N5 delivers the reliability and precision required for hazardous-location visual warning, industrial safety notification, and marine signaling applications.
