Product Description P/N: 867STRR-N5
Description
The Edwards Signaling 867STRR-N5 Horn/Strobe Unit is a combination audible and visual notification appliance designed for indoor fire alarm and emergency signaling applications. Featuring a high-visibility red xenon strobe and an integrated electronic horn, it provides effective occupant notification in commercial, institutional, and industrial facilities.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Edwards Signaling |
| Category | Audible & Visual Signaling Devices |
| Part Number | 867STRR-N5 |
| Subcategory | Horn/Strobe Units |
| Series | 867STR Series |
| Model | 860STR |
| Product Type | Electronic Horn/Strobe |
| Visual Function | Strobe |
| Audible Function | Horn |
| Operating Voltage | 120 VAC |
| Operating Current (Strobe) | 0.115 A |
| Operating Current (Horn) | 0.033 A |
| Lamp Type | Xenon |
| Lens Color | Red |
| Light Intensity | 21 cd |
| Flash Rate | 60 FPM |
| Sound Intensity | 90 dB at 10 ft |
| Housing Material | Gray Engineered Thermoplastic |
| Mounting Type | Surface Mount, 3-5/16 in Deep Square Box |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Approvals | UL 1638 (Strobe), UL 464 (Horn) |
| Dimensions | 5-1/2 in W x 5-1/2 in H |
| Weight | 0.42 lb (0.19 kg) |
Information About 867STRR-N5
The 867STRR-N5 is part of the Edwards 867STR Series of signaling devices, engineered to combine strobe and horn functionality within a compact, durable housing. Operating on 120 VAC, the unit utilizes a xenon strobe lamp producing 21 candela of visual output and an electronic horn delivering 90 dB at 10 feet. The gray engineered thermoplastic housing is designed for indoor environments and mounts to a 3-5/16-inch deep square box for straightforward installation. With independently operating horn and strobe circuits, the appliance offers flexibility for a variety of life safety and emergency communication system designs.
Key Features:
- Combined Horn and Strobe: Provides both audible and visual emergency notification.
- Red Xenon Strobe Lens: Delivers highly visible signaling for occupant awareness.
- Surface-Mount Design: Enables quick installation on compatible electrical boxes.
- 21 Candela Output: Provides effective visual notification coverage.
- 90 dB Horn Output: Generates a clear audible warning signal.
- Independent Circuit Operation: Horn and strobe functions can operate separately.
- Durable Thermoplastic Housing: Designed for long-term indoor service.
- UL Listed Device: Certified to UL 1638 and UL 464 standards.
The 867STRR-N5 delivers the reliability and precision required for indoor fire alarm notification and emergency signaling applications.
