EGB14020EPD | Square D 20A 277V 1-Pole Molded Case Circuit Breaker – Thermal Magnetic, EGB Series
- Regular price
- $825.00
- Sale price
- $825.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EGB14020EPD
Description
The Square D EGB14020EPD is a molded case circuit breaker designed for high-performance electrical protection in lighting and power distribution systems. This 1-pole, 20 A breaker operates at 277 V AC with a 35 kA interrupting capacity at 480 V AC, providing dependable thermal-magnetic protection. It features a bolt-on mounting design and is specifically engineered for use in Square D NF panelboards.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | EGB14020EPD |
| Subcategory | Molded Case |
| Series | EGB Series |
| Frame Type | E-Frame |
| Poles | 1 |
| Voltage Rating | 277 V AC |
| Amperage Rating | 20 A |
| Interrupting Capacity | 35 kA @ 480 V AC, 65 kA @ 120 V AC |
| Trip Unit Type | Thermal-Magnetic (LI – Long-Time & Instantaneous) |
| Mounting Type | Bolt-On |
| Connection Type | Lug (AWG 14–6 Cu, AWG 12–4 Al) |
| Panel Compatibility | NF Panelboard |
| Protection Type | Overload and Short-Circuit |
| Temperature Rating | Calibrated for 40°C |
| Certifications | cULus |
| Standards Compliance | HACR, HID, Switching Duty Rated |
| Body Material | Thermoset Composite Resin |
| Country of Origin | Mexico |
| Dimensions (H × W × D) | 6.64 × 1.96 × 4.05 in |
| Weight | 2 lb (0.9 kg) |
Information About EGB14020EPD
The EGB14020EPD is part of the Square D EGB Series molded case circuit breakers, built for consistent, durable operation within commercial and industrial electrical systems. It incorporates a thermal-magnetic trip mechanism combining long-time overload and instantaneous short-circuit protection for safe and efficient circuit management. The breaker features a compact E-Frame design and bolt-on mounting for easy installation and maintenance in NF panelboards. Certified to cULus standards, the EGB14020EPD ensures dependable performance even under demanding electrical load conditions.
Key Features:
- Voltage Rating: Operates at 277 V AC for single-phase electrical distribution.
- Current Rating: Rated at 20 A for reliable circuit protection in NF panelboards.
- Interrupting Capacity: Provides 35 kAIC at 480 V AC and 65 kAIC at 120 V AC.
- Trip Unit Type: Thermal-magnetic unit combines long-time and instantaneous trip protection.
- Mounting Type: Bolt-on design ensures stable and secure panel installation.
- Connection Type: Lug terminals support AWG 14–6 copper or AWG 12–4 aluminum wiring.
- HACR and HID Rated: Suitable for HVAC and high-intensity discharge lighting systems.
- Certified Safety: Complies with cULus standards and calibrated for 40°C operation.
The EGB14020EPD delivers the reliability and precision required for professional-grade overload and short-circuit protection in power distribution networks.
