EGH1020FFB | Eaton 20A 1-Pole 600Y/347 VAC Series G Molded Case Circuit Breaker (EG Frame)
- Regular price
- $269.00
- Sale price
- $269.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EGH1020FFB
Description
The Eaton EGH1020FFB is a 1-pole molded case circuit breaker designed for dependable circuit protection in industrial and commercial electrical systems. With a current rating of 20 amps and a voltage rating of 600Y/347 VAC, it features a thermal-magnetic trip mechanism for overload and short-circuit protection. The breaker provides a high interrupting capacity of up to 100 kAIC at 240 VAC, making it suitable for demanding high-performance installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton / Cutler-Hammer |
| Category | Circuit Protection |
| Part Number | EGH1020FFB |
| Subcategory | Molded Case Circuit Breaker |
| Series | Series G |
| Frame Type | EG Frame |
| Number of Poles | 1 |
| Amperage Rating | 20 A |
| Voltage Rating | 600Y/347 VAC |
| Interrupting Rating | 100 kAIC at 240 VAC / 65 kAIC at 480 VAC / 35 kAIC at 600Y/347 VAC |
| Trip Type | Fixed Thermal-Magnetic |
| Functions | Long-Time and Instantaneous |
| Connection Type | Bolt-On |
| Terminal Type | Line and Load Lugs |
| Frequency Rating | 50/60 Hz |
| Approvals | UL Listed, CSA Certified, CE Marked, IEC Rated |
| Mounting Type | Panel Mount |
| Operating Temperature | 40 °C Standard |
| Dimensions (H × W × D) | 5.5 × 1 × 2.99 in |
| Country of Origin | USA / Philippines |
| Weight | 1 lb |
Information About EGH1020FFB
The EGH1020FFB is part of Eaton’s Series G family of molded case circuit breakers, known for their compact design, high breaking capacity, and global compliance with UL, CSA, IEC, and CE standards. Built with an EG frame, this breaker includes bolt-on terminals for secure connections and supports both 50 Hz and 60 Hz operation. The fixed thermal and magnetic trip units ensure consistent protection under varying load conditions. Designed for easy integration, the EGH1020FFB fits a wide range of panels and switchboards, offering global acceptance and field-ready installation options.
Key Features
- High Interrupting Rating: Supports up to 100 kAIC at 240 VAC for superior fault protection.
- Thermal-Magnetic Trip Unit: Provides reliable long-time and instantaneous protection.
- Global Compliance: Certified under UL, CSA, IEC, and CE standards for worldwide use.
- Compact Form Factor: Reduces panel space requirements while maintaining performance.
- Bolt-On Connection: Ensures a strong and secure terminal interface for safe operation.
- Advanced Contact Design: High-speed blow-open mechanism enhances arc suppression.
- Dual Frequency Support: Operates efficiently on both 50 Hz and 60 Hz systems.
- Durable Construction: Built with industrial-grade materials for long operational life.
The EGH1020FFB delivers the reliability and precision required for industrial and commercial circuit protection in high-demand electrical systems.
