EGH3035FFG | Eaton 3 Pole Circuit Breaker
- Regular price
- $1,367.00
- Sale price
- $1,367.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EGH3035FFG
Description
The Eaton EGH3035FFG is a 3‑pole, 35 A thermal‑magnetic molded case circuit breaker from Eaton’s Series G (EG‑frame)—engineered for global applications and compact low-voltage power systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Eaton |
| Category |
Contactors & Starters
|
| Part Number | EGH3035FFG |
| Subcategory | Starters |
| Amperage Rating |
35 A |
| Voltage Rating | 600Y/347 Vac |
| Trip Type |
T186
|
| Circuit Breaker Type | EG |
| Circuit Breaker Frame Type | Complete breaker |
| Series | Series G |
| Terminals | Line and load |
| Frame | EG |
| Frequency Rating | 50/60 Hz |
| Interrupt Rating | 35 kAIC at 600Y/347 Vac 100 kAIC at 240 Vac 65 kAIC at 480 Vac |
| Number of Poles | Three-pole |
| Terminal Connection | Line and Load Side Lug |
| Protection | Thermal Magnetic |
| Temperature Rating | 40°C |
| Actuator Type | Toggle |
| Phase | 3 |
| Length/Depth | 2.99 in |
| Height | 5.5 in |
| Width | 3 in |
| Weight | 2.89 lbs |
Information About EGH3035FFG
The EGH3035FFG is part of Eaton’s Series G molded case circuit breaker family—compact, high-performance solutions designed for global low-voltage power distribution systems. This 3-pole, 35 A thermal-magnetic breaker features fixed long-time and instantaneous protection and supports operating voltages up to 600Y/347 VAC. With exceptional interrupting capacities up to 100 kA at 240 VAC, it is built for demanding industrial, OEM, and commercial panelboard applications. Its bolt-on design, compact footprint, and global certifications make it an ideal choice for both new installations and retrofit projects.
Key Features:
- 3-Pole, 35 A Protection: Provides reliable overcurrent protection for three-phase loads, including motors, distribution circuits, and control panels.
- High Interrupting Ratings: Delivers fault-clearing performance of 100 kA at 240 VAC, 70 kA at 415 VAC, 65 kA at 480 VAC, and 35 kA at 600Y/347 VAC—ensuring safe operation in high-energy environments.
- Thermal-Magnetic Trip Unit: Fixed long-time and instantaneous trip functions provide effective protection against overloads and short circuits.
- Bolt-On Installation: Facilitates quick and secure mounting into panelboards and switchgear using standard line and load lugs.
- Global Voltage Support: Rated for systems up to 600Y/347 VAC, making it suitable for North American and international power grids.
- Compact Form Factor: Measures just under 6 inches in length, optimizing valuable panel space while delivering robust performance.
- Certifications & Compliance: UL 489 listed, CSA certified, IEC compliant, CE marked, and RoHS compliant—ready for international deployment.
- Durable Construction: Built with industrial-grade materials and designed for high reliability in mission-critical applications.
- OEM and Panelbuilder Friendly: Well-suited for switchgear builders, machinery manufacturers, and maintenance teams seeking consistent, proven circuit protection.
- Same-Day Availability: Commonly stocked through Eaton distributors, with quick shipping for urgent replacement or project requirements.
The Eaton EGH3035FFG molded case circuit breaker offers robust three-phase protection, global certification, and compact design—making it a top-tier solution for engineers, OEMs, and electrical professionals building high-performance industrial and commercial systems.
