EGH3040FFB | Eaton 3 Pole Circuit Breaker
- Regular price
- $1,154.00
- Sale price
- $1,154.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EGH3040FFB
Description
The Eaton EGH3040FFB is a 3-pole molded case circuit breaker from the Series G family, engineered for reliable overcurrent protection in commercial and industrial electrical systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Eaton |
| Category |
Circuit Breaker
|
| Part Number | EGH3040FFB |
| Subcategory | Molded Case Circuit Breaker |
| Family | Series G |
|
Type |
EGH |
| Voltage Rating | 600Y/347 VAC |
| Interrupting Capacity @ 240V AC | 100 kAIC |
| Interrupting Capacity @ 480V AC | 65 kAIC |
| Pole Configuration | 3 Pole |
| Current Rating |
40 Amps |
| Trip Unit Type |
Fixed Thermal-Magnetic |
| Termination Style | Bolt-On |
| Weight |
3 lbs
|
Information About EGH3040FFB
The Eaton EGH3040FFB is a molded case circuit breaker from Eaton's Series G, designed for robust overcurrent protection in commercial and industrial electrical systems. This 3-pole, 40-amp breaker operates at up to 600Y/347V AC and features fixed thermal and magnetic trip units for consistent performance. With high interrupting capacities—100 kAIC at 240V AC, 65 kAIC at 480V AC, and 35 kAIC at 600Y/347V AC—it ensures reliable fault current protection. The bolt-on design facilitates straightforward installation, and its compact dimensions (3.00" W x 5.50" H x 2.99" D) and 3-pound weight make it suitable for various panelboards and switchboards. The EGH3040FFB is UL Listed, CSA Certified, CE Marked, and IEC Rated, ensuring compliance with international safety standards.
electrical.com
Key Features:
- Current Rating: 40 Amps
- Voltage Rating: Up to 600Y/347V AC
- Interrupting Capacity:
- 100 kAIC at 240V AC
- 65 kAIC at 480V AC
- 35 kAIC at 600Y/347V AC
- Trip Unit: Fixed Thermal and Magnetic
- Poles: 3
- Mounting: Bolt-On
- Dimensions: 3.00" W x 5.50" H x 2.99" D
- Weight: 3 lbs
- Certifications: UL Listed, CSA Certified, CE Marked, IEC Rated
The EGH3040FFB delivers high-capacity protection and reliable performance, making it an ideal choice for power distribution, motor control centers, and critical industrial systems.
