EHB125SL | Square D 125A 1-Pole 120V Molded Case Circuit Breaker for NEHB Panelboards
- Regular price
- $626.00
- Sale price
- $626.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EHB125SL
Description
The Square D EHB125SL is a 1-pole, 125-amp molded case circuit breaker designed for dependable overcurrent and short-circuit protection in low-voltage power systems. Engineered for 120V applications, it uses a thermal-magnetic trip unit to ensure precise circuit interruption. The bolt-on mounting configuration makes it suitable for secure installation in Square D NEHB panelboards.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | EHB125SL |
| Subcategory | Molded Case |
| Series | EHB |
| Manufacturer | Schneider Electric |
| Amperage Rating | 125 A |
| Voltage Rating | 120 V |
| Poles | 1 |
| Trip Unit Type | Thermal Magnetic |
| Connection Type | Bolt-On |
| Mounting Type | Bolt-On |
| Protection Type | Overload and Short-Circuit |
| For Use With | NEHB Panelboards |
| Phase | 1 |
| Operating Frequency | 50/60 Hz |
| Frame Type | EHB Frame |
| Construction | Molded Case |
| Terminal Type | Lug |
| Application | Power Distribution and Protection |
| Country of Origin | United States |
| Weight | 1.14 lb |
Information About EHB125SL
The EHB125SL is part of the Square D EHB Series by Schneider Electric, known for its durable molded case construction and consistent performance in commercial power distribution. It integrates thermal-magnetic trip technology to provide both long-time overload and instantaneous short-circuit protection. The breaker is built for bolt-on mounting, ensuring a stable and reliable electrical connection within NEHB panelboards. With a 125A current rating and 120V operating capacity, it is ideal for single-phase power systems in lighting, HVAC, and general-purpose installations.
Key Features:
- High Current Capacity: Rated for 125 amps, supporting demanding single-phase power loads.
- Thermal-Magnetic Protection: Combines long-time and instantaneous trip mechanisms for complete circuit safety.
- Bolt-On Mounting: Provides secure and vibration-resistant installation in NEHB panelboards.
- Compact Design: Saves space while delivering high interrupting performance in confined enclosures.
- Reliable Connection: Lug terminals ensure stable electrical conductivity with minimal maintenance.
- Durable Molded Case: Resistant to mechanical stress and thermal fluctuations for long service life.
- Certified Quality: Manufactured by Square D, meeting industrial performance and safety standards.
The EHB125SL delivers the reliability and precision required for dependable power protection in commercial and industrial electrical systems.
