EL1004 | BECKHOFF EtherCAT 4-Channel Digital Input Terminal, 24 V DC, 3 ms Filter
- Regular price
- $79.00
- Sale price
- $79.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EL1004
Description
The Beckhoff EL1004 is a four-channel digital input terminal designed to capture 24 V DC binary signals for EtherCAT automation systems. It provides electrically isolated signal transmission to upstream controllers and includes a built-in 3 ms input filter for stable and debounce-free operation. Each channel features LED status indication for clear diagnostics during commissioning and operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | BECKHOFF |
| Category | PLCs/Machine Control |
| Part Number | EL1004 |
| Subcategory | PLC Programming Terminal |
| Product Type | Digital Input Terminal Module |
| Number of Inputs | 4 |
| Input Type | Digital |
| Module Type | Input |
| Supply Voltage | 24 V DC |
| Input Current | 90 mA (typ.) |
| Input Filter | 3 ms |
| Input Specification | Type 1/3 |
| Sensor Compatibility | 2-wire sensors supported |
| Signal Indication | LED per channel |
| Isolation | Electrical isolation between field and logic levels |
| Protection Rating | IP20 |
| Operating Temperature | –25…+60 °C |
| Storage Temperature | –40…+85 °C |
| Bus System | EtherCAT |
| Application | Digital signal acquisition for automation systems |
Information About EL1004
The EL1004 is part of the Beckhoff EL100x digital input terminal series, offering compact signal acquisition within modular EtherCAT architectures. It uses a Type 1/3 input specification and incorporates a 3 ms filter to eliminate switch bounce and ensure clean digital transitions. The module integrates easily with EtherCAT I/O stations and supports direct wiring of four 2-wire sensors through additional 24 V connection points. Typical usage includes machine control, distributed I/O systems, and industrial automation applications requiring reliable digital signal capture with fast fieldbus communication.
Key Features:
- Four digital inputs: Captures 24 V DC binary signals for EtherCAT systems.
- Integrated input filter: 3 ms filtering minimizes bounce and enhances signal stability.
- LED indication: Each channel includes a state LED for straightforward diagnostics.
- Electrically isolated transmission: Ensures reliable communication to higher-level controllers.
- Compact EtherCAT design: Fits seamlessly into modular Beckhoff I/O stations.
- Direct sensor connection: Supports four 2-wire sensors with additional 24 V terminal points.
- Type 1/3 input specification: Optimized for industrial digital sensing applications.
- Wide temperature tolerance: Operates in harsh environments from –25 to +60 °C.
The EL1004 delivers the reliability and precision required for distributed digital signal acquisition in modern EtherCAT-based automation systems.
