Euchner TQ1-0302G024-5000 24 VDC Locking Safety Switch with 5m Cable
- Regular price
- $507.00
- Sale price
- $507.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TQ1-0302G024-5000
Description
The Euchner TQ1-0302G024-5000 is a compact locking safety switch designed to secure and monitor machine guards in industrial environments. It features spring-force guard locking, a 24 VDC solenoid, and three positively driven door-position contacts with two guard-lock monitoring contacts. Its IP67-rated reinforced thermoplastic housing and pre-assembled 5-meter connecting cable support flexible installation in compatible safety systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Euchner |
| Category | Safety Switches |
| Part Number | TQ1-0302G024-5000 |
| Subcategory | Safety Switches |
| Series | TQ |
| Voltage | 24 V DC |
| Protection | IP67 |
| Locking | Spring-force |
| Force | 500 N |
| Contacts | 3 NC + 2 NC |
| Power | 2.7 W |
| Cable | 5 m |
| Temperature | -20 °C to +50 °C |
| Insulation | 300 V |
| Frequency | Max. 900 cycles/h |
| Housing | Reinforced thermoplastic |
| Weight | 0.601 kg |
Information About TQ1-0302G024-5000
The TQ1-0302G024-5000 is part of the Euchner TQ series of compact safety switches with integrated guard locking. Its closed-circuit current principle keeps the guard locked by spring force and releases the mechanism when voltage is applied to the solenoid. An LED indicator provides operating status visibility, while auxiliary release access from three sides supports manual unlocking requirements. The slow-action switching mechanism and 100% solenoid duty cycle are suited to continuous machine safety monitoring.
Key Features:
- Guard Locking: Spring-force locking mechanism with electrical solenoid release for controlled machine guard access.
- Contact Configuration: Includes 3 positively driven door-position contacts and 2 NC guard-lock monitoring contacts.
- Solenoid Voltage: Operates on 24 VDC with a 100% duty cycle.
- Locking Force: Provides a maximum locking force of 500 N for compatible guard applications.
- Protection Rating: IP67 housing protection against dust and water ingress.
- Connecting Cable: Supplied with a pre-assembled 5-meter connecting cable for simplified installation.
- Auxiliary Release: Features auxiliary release access from three sides for manual unlocking.
- Status Indicator: Integrated LED indicator provides visual operating status.
The TQ1-0302G024-5000 delivers the reliability and precision required for industrial machine guarding and safety interlock applications.
