EVF3233-5DZB-01F | SMC Solenoid Valve
- Regular price
- $167.00
- Sale price
- $167.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: EVF3233-5DZB-01F
Description
The SMC EVF3233‑5DZB‑01F is a pilot-operated, body‑ported version of the VF3000 series 4/5-port solenoid valve, designed for industrial pneumatic directional control with internal pilot exhaust (LQA configuration), typically supplied as a surplus or independent-line item.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | SMC |
| Category |
Valves
|
| Part Number | EVF3233-5DZB-01F |
| Subcategory | Solenoid Valve |
| Series | VF3000 |
| Valve Type | Solenoid Valve |
| Actuation Type | Pilot-Operated |
| Port Configuration | Body Ported |
| Special Configuration | LQA (Internal Pilot Exhaust Configuration) |
| Number of Ports | 5-Port (4/5-port type) |
| Valve Style | Inline, Body Ported |
| Operating Pressure Range | Typically 0.15–1.0 MPa (varies by model) |
| Mounting Style | Body-mounted (non-manifold) |
| Pilot Exhaust | Internal (with LQA configuration) |
| Voltage Type | DC or AC coil depending on suffix ("5DZB") |
| Manual Override | Locking Slotted Type (Z) |
| Electrical Entry | DIN terminal (B) |
| Piping Type | Threaded body ports |
| Weight | 1.42 lbs |
Information About EVF3233-5DZB-01F
The EVF3233-5DZB-01F is a pilot-operated 5-port solenoid valve from SMC’s VF3000 series, engineered for efficient directional control in pneumatic automation systems. Designed with a body-ported layout and internal pilot exhaust (LQA configuration), this robust valve delivers high flow capacity and stable actuation for a wide range of industrial applications. With its compact construction, DIN terminal connection, and optional manual override, it is ideal for use in control cabinets, process machinery, and multi-axis pneumatic systems.
Key Features:
- Pilot-Operated 5-Port Valve: Ensures reliable directional control of air flow in both 4- and 5-port configurations, suitable for double-acting cylinders and complex actuator systems.
- Body-Ported with LQA Configuration: Internal pilot exhaust routing eliminates external venting, streamlining panel layout and simplifying installation.
- Compact Inline Design: Optimized for space-saving applications; allows easy integration into pneumatic manifolds or individual valve stations.
- DIN Terminal Electrical Entry: Standardized electrical interface supports fast, secure connections and simplifies maintenance.
- Manual Override (Slotted Locking): Enables manual actuation during setup or emergency operation without electrical input.
- Durable Construction: Built with high-performance materials and engineering precision to ensure long service life in demanding industrial settings.
- Series Compatibility: Part of the VF3000 family, allowing seamless compatibility with manifold blocks, accessories, and SMC’s air control ecosystem.
- Reliable Performance: Supports fast response times, consistent switching, and low power consumption — ideal for automation sequences requiring dependable actuation.
The SMC EVF3233-5DZB-01F solenoid valve combines precision actuation, compact design, and industry-proven reliability. It is an essential choice for machine builders, automation engineers, and OEMs requiring modular, high-performance pneumatic control in body-ported, pilot-actuated configurations.
