FA36040 | Schneider Electric I-Line FA Molded Case Circuit Breaker 40A 3-Pole 600V
- Regular price
- $909.00
- Sale price
- $909.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FA36040
Description
The Schneider Electric FA36040 is a molded case circuit breaker designed for reliable overcurrent protection in industrial and commercial power distribution systems. Rated at 40 A and 600 V, this 3-pole I-Line breaker uses a thermal magnetic trip mechanism to protect circuits from overloads and short-circuit conditions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Circuit Breaker |
| Part Number | FA36040 |
| Subcategory | Molded Case Circuit Breaker |
| Series | I-Line |
| Breaker Type | FA |
| Line Rated Current | 40 A |
| Voltage Rating | 600 V |
| Number of Poles | 3 |
| Phase Connection | ABC |
| Interrupt Rating | 14 kA @ 600 V |
| Breaking Capacity Code | A |
| Trip Unit Technology | Thermal Magnetic |
| Magnetic Hold Current | 400 A |
| Magnetic Tripping Current | 850 A |
| Mounting Mode | I-Line Plug-In |
| Terminal Identifier | AL50FA |
| Circuit Breaker Application | HACR Rated |
| Temperature Rating | 40 °C |
| Height | 6.4 in (162.56 mm) |
| Width | 4.5 in (114.30 mm) |
| Depth | 4.13 in (104.90 mm) |
Information About FA36040
The FA36040 is part of the Schneider Electric I-Line Type FA product family, engineered for three-phase electrical distribution applications. Its molded case construction and I-Line plug-in design support quick installation and simplified servicing in compatible panelboard systems. The breaker incorporates a thermal magnetic trip mechanism that delivers long-time protection against sustained overloads and instantaneous response to short-circuit events. Designed for operation at ambient temperatures up to 40 °C, it is well suited for industrial and commercial environments requiring dependable circuit protection at higher voltages.
Key Features
- I-Line FA Series Design: Developed for seamless integration into Schneider Electric I-Line panelboards.
- 40A Current Rating: Suitable for low to medium load three-phase branch circuit applications.
- Three-Pole Configuration: Provides coordinated protection across all three phases.
- Thermal Magnetic Trip Mechanism: Combines overload and short-circuit protection in a single device.
- 14 kA Interrupting Capacity: Rated to safely interrupt fault currents at 600 V.
- I-Line Plug-In Mounting: Enables fast installation and efficient maintenance without hard wiring.
- HACR Rated Construction: Approved for heating, air conditioning, and refrigeration circuit applications.
The FA36040 delivers the reliability and precision required for protecting three-phase circuits in Schneider Electric I-Line power distribution systems used in demanding industrial and commercial installations.
