FD1090 | Eaton Series C Complete Molded Case Circuit Breaker
- Regular price
- $687.00
- Sale price
- $687.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: FD1090
Description
The FD1090, part of the Eaton Series C, is a complete molded case circuit breaker designed for various electrical applications. Featuring an F-frame design, it offers durability and reliability in circuit protection. The FD1090 is a single-pole breaker with a fixed thermal and fixed magnetic trip type, ensuring efficient protection against overloads and short circuits.
Technical Specifications
|
Product Name |
Eaton Series C complete molded case circuit breaker |
|
Catalog Number |
FD1090 |
|
UPC |
786679312186 |
|
Product Length/Depth |
3.38 in |
|
Product Height |
6 in |
|
Product Width |
1.38 in |
|
Product Weight |
4.5 lb |
|
Amperage Rating |
90 A |
|
Voltage Rating |
347 Vac, 125 Vdc |
|
Trip Type |
Fixed thermal, fixed magnetic |
|
Circuit Breaker Type |
FD |
|
Circuit Breaker Frame Type |
Complete breaker |
|
Series |
Series C |
|
Terminals |
Load side |
|
Frame |
F |
|
Frequency Rating |
50/60 Hz |
|
Interrupt Rating |
35 kAIC at 277 Vac |
|
|
18 kAIC at 347 Vac |
|
Number of Poles |
Single-pole |
The FD1090, an offering from Eaton, belongs to the Series C complete molded case circuit breaker lineup. Classified under the F-frame category, it is designated as an FD model. This circuit breaker is a complete unit, incorporating both fixed thermal and fixed magnetic trip mechanisms. Operating as a single-pole device, it carries an amperage rating of 90 A. Its voltage handling capabilities encompass 347 Vac and 125 Vdc.
Regarding its interrupt rating, the FD1090 exhibits a capacity of 35 kAIC at 277 Vac and 18 kAIC at 347 Vac, ensuring robust protection against overcurrent situations. Designed for compatibility with a frequency range of 50/60 Hz, it is optimized for a variety of power system configurations.
Physically, this circuit breaker measures 3.38 inches in length/depth, 6 inches in height, and 1.38 inches in width. It weighs approximately 4.5 pounds, making it relatively compact and manageable for installation and maintenance procedures.
Information About FD1090
The BJ2150 is a main circuit breaker manufactured by Eaton. Designed as part of the Type BJ series, it features a 1-inch plug-on configuration, catering to a wide array of electrical applications. With a robust amperage rating of 150 A, this circuit breaker is suitable for handling substantial electrical loads. It boasts a high interrupt rating of 10 kAIC, ensuring reliable circuit protection against overloads and short circuits.
This two-pole circuit breaker operates within a voltage range of 120/240 V, making it compatible with standard residential and commercial electrical systems. The trip type is common, providing consistent performance across both poles. Installation is simplified with its plug-on mounting method, streamlining the setup process.
Constructed to meet rigorous industry standards, the BJ2150 is engineered for durability and longevity. Its circuit breaker frame type is designated as BJ, denoting its specific design and compatibility. The connection mechanism is plug-on, facilitating secure and efficient wiring practices.
